10km Man Thermal Camera Surveillance Electro-Optics System_Surveillance Equipment_Security & Protection_Products

Top Selling

品牌：: TianYing

Model: TY-P3

Origin: Made In China

Label: thermal camera , camera system , surveillance system

China TianYing TY-P3 electro-optics system is specially designed for precise alignment, clear surveillance tracking, and accuracy measuring target moving data. the system is including coaxial wide spectral band CCTV camera, coaxial long focus cooled thermal imaging, high rate long range eye safe laser rangefinder, high accurate mid-speed turret and auto tracker.

With its combination of a large field of view for wide-area observation and detection, and an extremely small field of view for identification, it fulfills the highest requirements for the seamless surveillance of land and maritime borders. High-performance technology that you can rely on at any time.

The system features line of sight of coaxial cameras and turret is bore-sighted with laser rangefinder, then up to effective accurate measurement and air defense. The TY-P3 can be operated as a stand-alone or integrated into existing legacy operating systems.The camera is suited for use in stationary solutions - for example mounted on masts, tripods, vehicle or building structures - as well as mobile applications.

TY-P3 measuring tracking surveillance EO/IR thermal camera system features:
1) Effective accurate measurement due to precise alignment target of coaxial camera with LRF and turret.

2) Long range no chromatic aberration HD coaxial zoom quick auto day sight TV camera with SWIR NIR.

3) Ultra long range SD coaxial zoom cooled infrared thermal imaging sight camera.

4) Tracking grade high accuracy high rate long range eye safe laser rangefinder.

5) Auto tracker function with analog video, option digital video.

6) Compact r edized design with hermetically sealed house (weight < 120 kg).

Recommended Use:
1, Observation and targeting.

2, Target identification and tracking.

3, Target measurement and position determination.

4, Ultra long range photo and video.

5, Anti-aircraft early warning.

6, Against land, sea and air target fire control.

TY-P3 measuring tracking surveillance EO/IR thermal camera system specifications:

Model	TY-P3
Thermal Camera
Detector	Cooled FPA 15microns 640 x 512 pixels
Spectral band	3μm~5μm
Focal length - Option 1	40/200/1000mm (N:0.55°, M: 2.7°, W: 13.7° for FOV horizontal)
Focal length - Option 2	110 to 1100mm continuous zoom (0.5° to 5° for FOV horizontal)
Focal length - Option 3	55 to 1100mm continuous zoom (0.5° to 10° for FOV horizontal)
Focal	Manual, Automatic
Sensor Start-Up Time	< 8 min (+ 20° C)
Alignment	Coaxial zoom
Detection human range	Approx 15 km
Recognition human range	Approx 10 km
Day Light Camera(digitalization + intellectualization)
Detector	Global exposure micron 1920 x 1080 pixels
Focal length	13mm~800mm continuous optical zoom.
Wavelength	400nm ~ 1100nm (0.4μm~0.7μm daylight, 0.7μm~1.1μm NIR SWIR)
Focus	Quick automatic with no shift, including switching mode
Alignment	Coaxial zoom
Advantage features	No chromatic aberration, supper defog,focus coplanar,ultra-long life etc
Real-time data backhaul	focal length preset, focusing preset, zoom to specify focal length etc
Lens control	electric zoom, electric/auto focus, electric/auto optical filter
Detection range	Approx 15km for human, Approx 20km for 6m x 3m vehicle/boat
Recognition range	Approx 8km for human, Approx 18km for 6m x 3m vehicle/boat
Laser Range Finder- Option-1
Wavelength	1.57μm
Beam divergence	≤ 1 mrad
Typical ranging	>25km (>15km for 30% albedo 5m² craft) in standard visibility 23.5km
Measuring rate	1Hz continuous 10minutes
Measurement accuracy	≤ 2m (RMS)
Safety class	Class 1(EN 60825-1:2007)
Laser Range Finder- Option-2
Wavelength	1.57μm
Beam divergence	≤ 1 mrad
Typical ranging	>30km (>16km for 30% albedo 5m² craft) in standard visibility 23.5km
Measuring rate	5Hz work 30 seconds and rest 30 seconds cycle at +60ºC
Measurement accuracy	≤ +/-1m
Safety class	Class 1M or 3R (EN 60825-1:2007)
Pan/Tilt Turret
Accuracy	0.01°
Direction range	azimuth:360° continuous; elevation:+45°~-45°
Directing speed range for azimuth	0.01°/s to 45°/s
Directing speed range for elevation	0.01°/s to 45°/s
Parking Position	Yes
Programmable Search	Program multiple preset scene locations
Communication protocol	Pelco-D
Environmental
Operating temperature range	-32ºC ~ +60ºC, option -40ºC ~ +60ºC
Storage temperature range	-40ºC ~ +70ºC
Protection level	IP66
Power
Power Supply	220V AC / DC 24V
Power consumption	≤ 200W (average for typical operation profile)
System Features and Physical
Auto tracking	Yes
Boresighting	line of sight of cameras is boresighted with laser rangefinder
Size	appr. 950 mm x 650 mm x 635 mm
Weight	appr. 95kg
Note	1, Technical information is subject to change without notice. 2, Depending on the region of sale.
