12090 Brushless Motor High-power 15kw Brushless Motor

Product Description:

this is an outrunner brushless motor which uses motor can be low KV, large torque and direct drive. its accessories include: packet,prop, adapter, mounting seat. the two covers of the motor are made with slot to conduct the wind and cool off the motor. this design has been granted a patent.

Product Scope:

Since this is a high-power and high-thrust brushless motor been widely used in large-scale UAV,  This motor can significantly improve UAV's payload, in other words the UAV can Loaded Large-capacity of Batteries,  making the UAV flight time been extended,  when the motor is used for large-scale multi-axis UAV, its payload and flight time is longer,  At present, long-endurance unmanned aerial vehicle on the market is still blank. So,  this motor for Application in long-endurance UAV prospect is great !

Spec:

MOTOR: 12090

KV: 50,80,130,140,180

MAX POWER: 15000W-18000W

WIRE WINDS:

MAX AMP: 200A

ESC: 200 / 250A

MAX VOLT: 30v / 70v

NO LOAD CURRENT: 16,5

RESISTANCE (Ohm): .64

SIZE: 120 x 90 ( without include shaft )

Stator: 160 x 40mm

WEIGHT (kg): 2.835

SHAFT: 10mm Accessory pack: Yes

Recommended propeller：32*10 inch

Tips:

To run this motor buyer need to buy extra the following  parts:

1, 20S/300A ESC （Electronic speed controller）

2， More than 6 channel radio remote control and receiver.

3， 20S high-power lithium battery
