12V- 24VDC waterproof metal keypad single door standalone access controller

Main Features

1.metal shell, anti-vandal, more secure, waterproof design.
2.Backlight keypad.
3. Convenient for operating on night.
4.Large Capacity: 2,000 users.
5.Support 3 Modes Access: Card, PIN, Card+PIN.
6.Card Type: 125KHz EM, PIN length: 4～8 digits.
7. Operating Voltage: 12～18V AC/12～24V DC.
8. Very low power consumption ( ≤35mA), long service life and stable performance.
9. High Speed Search: filled with 2,000 users, the search time < 0.1 seconds.
10.Manage cards: the manage cards can add/delete the users directly, very convenient
11. Wiegand 26 input & output, can work as Wiegand reader/Controller.
12 Protective properties: IP65 fully-potted. with anti-demolition, alarm function, anti-static
---interference 12KV.
13.Operating Temperature: -40℃～60℃.

Specifications

A.Operating Voltage: 12～18V AC/12～24V DC
B. Adjustable Door Relay Time: 0～99s
C. Static Current: ≤35mA
D. Wiegand Interface: Wiegand 26
E. Card Read Rang: 3～6cm
F. Reader Induction Time: ≤0.1s
G. Operating Temperature: -40℃～60℃
H. Operating Humidity: 0%～95%
I.Lock Output Load: ≤1A
J. Alarm Output Load: ≤3A
K. Antistatic: 12KV
L. Environment: Conforms to IP65
M.Wiring Length: 90～100CM
N. Signal Light: red, green, yellow LED light display
O.Dimensions: L 135mm×W58mm×H 26mm

Packing List

1 × Digital Keypad
1 × User Manual
1 × Screw Driver
4 × Rubber Bungs
4 × Self Tapping Screws
2 × Manager Card
