180kg Single Door Magnetic Lock with Signal DW-180S
TOP selling point
1.12V and 24V optional in the same electromagnet door lock
2.With led light indicator
3. Support NO/NC/Com signal output
4. 180kg 350lbs single door lock .
Product Parameter | Parameter Description |
Size | 183Lx41.4Wx20.5H(mm) |
Armature Plate Dimension | 130Lx33Wx9.3H(mm) |
Holding Force | 180kg(350Lbs) |
Input Voltage | 12/24VDC+10% |
Current | 12V/300mA 24V/150mA |
Signal | Lock status detection signal output |
Suitable | Wooden door , Glass door ,metal door , Fireproof door |
Surface Temp | ≤+20℃ |
Operating Temp | -10~+55℃(14-131F) |
Humidity | 0~90%(non-condensing) |
Cover Finish | Anodized aluminum |
Lock Finish | Zinc |
Armature Plate Finish | Zinc |
Weight | 1.2KG |
