2019 Updated Chicken Manure slant screen separator

~Slant Sieve Solid-liquid Separator

1. Product introduction
The slant sieve solid-liquid separator is a kind of livestock manure dewatering machine, which can separate raw manure water of livestock manure such as pig manure, duck manure, cow dung, chicken manure into liquid organic fertilizer and solid organic fertilizer. Liquid organic fertilizer can be directly used for crop utilization and absorption. Solid organic fertilizer can be transported to the area lacking in fertilizer, and can also play a role in improving soil structure. At the same time, it can be made into organic compound fertilizer through fermentation. The raw manure water is sent to the machine by a mud pump, and the solid material is squeezed and separated by a screw shaft placed in the screen, and the liquid flows out through the screen through the screen.

2.Working principle and working diagram

The waste water to be treated is evenly distributed to the slant screen surface through the overflow weir, because the surface gap of the screen is small and smooth, the back gap is large, the drainage is smooth, and it is not easy to block; the solid substance is trapped, and the filtered water flows out from the gap of the sieve plate. At the same time, under the oblique action, the solid substance is pushed to the lower end of the sieve plate to discharge, thereby achieving the purpose of solid-liquid separation. The slanting screen can effectively reduce the concentration of suspended solids in water and reduce the processing load of subsequent processes. It is also used in industrial production for solid-liquid separation and recovery of useful substances.
It is an excellent equipment for filtering or recovering solid or colloidal substances such as suspended solids, floating substance and sediment.
The use of the slant sieve solid-liquid separator has high automation level, simple operation, easy maintenance, large daily processing capacity, low power consumption, and is suitable for continuous operation. It is an ideal solid-liquid separation equipment for large-scale farms, which can greatly improve solid-liquid separation and benefits.

3.Product model

Model ECOX80
Total power（KW） 4.4
Voltage (V, HZ) 380
Length(mm) 1600
Width(mm) 1000
Height(mm) 1500
Weight（kg） 550
Inlet diameter（mm） 76
Waste water outlet diameter after separation (mm) 160
Diameter of overflow outlet（mm） 76
Screen size 0.2mm,0.25mm，0.5mm，0.75mm，1.0mm
Processing capacity (liquid  (solids content <50%), m3/h) 10-15

Remarks:
There is a difference of 2-6 cubic meters in the processing capacity of the solid material according to the viscosity and dryness of the material.
