24VDC Single color RGB RGBW DMX512 IP68 SS316L LED Pool Light

Product Name:

SUS316 Stainless Steel LED Swimming Pool Light

Model Number:

B4XC0357, B4XC0457,B4XC0318, B4XC0418,C4XC0357, C4XC0457,C4XC0318, C4XC0418

Application:

LANDSCAPE,Swimming Pool,Fountain,Garden,Underwater

High Light:

SS316L LED Pool Light, DMX512 LED Pool Light, RGBW Led Underwater Pond Lights



Product Description

Series B4XC is an 3*2W/3W/4W or 4**2W/3W/4W LED Underwater Lights for Pool lighting or other underwater lighting.The Housing and Accessory of the product is completely made of Stainless Steel SUS 316L#. Optional 0/1-10V,DALI, PWM,TRIAC dimming or DMX512 control upon request. ABS mounting sleeve included for easy installation. IP68 design and support underwater 2meters depth installation makes this this LED pool light ideal solution as underwater spotlight for fountains, pools, ponds, water gardens etc. for atmospheric or underwater lighting.



Features and Benefits:

Utilizes 3pcs or 4pcs 2W Osram or 3W RGB 3-in-1 LED as light source.24VDC low voltage input.Made of SUS316L stainless steel completely for housing and accessories.Symmetrical light output  and asymmetrical light output for options.Overheat sensor inside(Optional).IP68 waterproof,underwater installation in depth less than 1meter(advised). Use the silicone with good stickiness and thermal effect for reach the purpose of radiating and prevent moisture.Standard non-dimmable.(Optional dimmable support with DALI, 1~10V, PWM. ).PVC/ABS Mounting sleeve included.2 Years warranty.



Warning for COMI Landscape lighting's underwater pool lightWarning:
▪ Water must be allowed to go inside and outside sleeve freely without leaking from the other side.
▪ This IP68 luminaire made of SUS316L stainless steel,so DO NOT operate the lighting fixture out of water for over 15 minutes (cooling).



Material Specifications:

Front cover & Housing	Molding shaped stainless steel SUS316L#
Light Window	Step tempered glass.T=8mm
Gasket	EPDM gasket
Cable Gland	IP-68 PG-11 copper with nickel-coated
Lens	Optical lens,efficiency≥85%
PCB	Excellent heat conductivity aluminum. Coefficient of heat Conductivity≥2.0w/mk
LED Driver	Constant current output Single color LED=1-circuit output RGB 3in1 LED=3-circuit output
Power Cable	H05RN-F 21.0mm2,L=3.0m(for single color) H05RN-F 4X0.75mm2, L=3.0m(for RGB)
Application Environment	Temperature of water between -20˚C~40˚C,Underwater less than 1 meter depth.
Mounting Sleeve	PVC Mounting Sleeve (Included)
Dimmable Support (Optional)	Optional dimmable function support with DALI, 0~10V, PWM



Technical Specifications:

Item Number	Light Source	CRI (White)	Standard Lens	Selected Lens Degree (Θ1/2)	Input Voltage(V)	Typical Operating Current(mA)	Typical Power Consumption(W)	Typical Luminance(lm)	IK Rate (What is IK Rate?)
B4XC0357	3x2W Osram	Ra>80	B33D	25°	24Vdc	242	5.8	CW=406 WW=389	08
B4XC0457	4x2W Osram	Ra>80	B33D	25°	24Vdc	371	8.6	CW=619 WW=500	08
B4XC0318	3x3W RGB 3-in-1 Full Color	/	B34D	30°	24Vdc	R=120 G=134 B=134	9.2	111	08
B4XC0418	4x3W RGB 3-in-1 Full Color	/	B34D	30°	24Vdc	R=150 G=174 B=174	12	180	08
C4XC0357	3x2W Osram	Ra>80	C8	45°/35°	24Vdc	242	5.8	CW=406 WW=389	08
C4XC0457	4x2W Osram	Ra>80	C8	45°/35°	24Vdc	371	8.6	CW=595 WW=479	08
C4XC0318	3x3W RGB 3-in-1 Full Color	/	C8	45°/35°	24Vdc	R=120 G=134 B=134	9.2	111	08
C4XC0418	4x3W RGB 3-in-1 Full Color	/	C8	45°/35°	24Vdc	R=150 G=174 B=174	12	162	08

Notes:
1. COB LED for this 4XC LED Pool Light is avaible, inquire separately.
2. Specifications are subjected to change without notice.



Symmetrical light and asymmetrical Light output LED Pool Lights ( 3LEDs type is available)





Dimensional drawing for 4*2W or 4*3W LED Pool Lights



Notes:

1. The above drawing is for B4XC04 and C4XC04 LED pool lights. And the B4XC03 and C4XC03 pool lights are wiht the same dimension with above dimension.

2. Front cover with dia 150mm is available.





Symmetrical lens and asymmetrical lens for LED Pool lights:





Asymmetrical light effect for Underground recessed or Wall Recessed LED Swimming Pool Lights:





important Notes for SUS 316L# Stainless Steel LED Swimming Pool Lights:

This product is a high power LED pool lights.The standard color temperature of warm white is in range 2700-3200k ,neutral white in range 4000-4300K, cool white in range 6000-6500K.The standard input voltage is 24VDC .When you install the product, please check the date label on the product and the wire.Basic is Non dimmable. Optional PWM, 0/1 10V, DALI dimmable or DMX512 controllable support upon request.This low voltage light fixture 24VDC input, please prepare powerful power supply or 24VDC output transformer . Total demand of power is according to total p ower consumption +total power of cable impedance consumption.it is advised that the max output power of power supply(transformer) is more 25% than the total actual power of the lighting fixtures.All the lighting fixtures is required to connect with the power supply in parallel.When installation,always work with professional and liciensed technician or install by professional and liciensed technician.This is IP68 grade product. This IP68 luminaire made of SUS316L stainless steel, Water must be allowed to go inside and outside sleeve freely without leaking from the other side.so DO NOT operate the lighting fixture out of water for over 15 minutes (cooling).Applicable environment temperature : 20℃<fixture<+40℃.
