Model Item: IN-117D
Specification:
4.1 physical specification
Description | Specification & criteria |
PCB layer | 2layers |
PCB dimension(card reader board) | 45mm * 98mm; FR4 |
PCB dimension (hub board) | 35*98mm, FR4 |
PCB thickness | 1 mm |
cable length | 55Cm to PC motherboard |
|
|
|
|
metal housing | 0.6mm thickness metal |
All materials | RoHS compliant |
4.2 Electrical specification
Description | Specification & criteria | |||||||||
HUB Chipset | USB3.0 Hub controller chipset GL3520 88pin QFN, from Genes ogic, | |||||||||
Card reader controller | USB3.0 Card reader controller:Chipset GL3220, from Genes ogic | |||||||||
Media slots | 5slots for CF, SD, MS, XD, MicroSD respectively | |||||||||
File format | FAT/FAT32/NTFS/exFAT | |||||||||
Firmware upgrade | EEPROM, firmware upgradable. | |||||||||
Indicator | 2 LEDs for flash card acc., Power | |||||||||
Interface operation | USB3.0 19pin header to PC mainboard, DC plug connected for more power | |||||||||
Operating voltage | 5Vdc input, USB BUS POWERED | |||||||||
Power consumption | <500mA
4.3 Operating System supported, NO DRIVER REQUIRED:
|
