4U 36 bays hot swap server chassis_Computer Components_Computers & AV Digital_Products

Top Selling

品牌：: OUMAN R465-36

Model: OUMAN R465-36

Origin: Made In China

Label: 36 bays server case , hot swap server case , 4U 36 bays chassis

Specification
Product SKUs - Discontinued SKU. Please contact sales-rep for possible OEM production quantities. MOQ may apply
		System Cooling
Model	OUMAN R465-36 (Steel)	Fans	3* 120mm two ball high-speed fans
			2*80mm two ball high-speed fans
Form Factor			add-on card (optional)
650mm Depth 4U Rackmount Chassis - supports UIO form factor motherboard with maximum size of ATX 12"x13“
		Operating Environment (System)
Dimensions		Operating Temperature Range	5°C ~ 35°C (41°F ~ 95°F)
Width	482mm	Non-Operating Temperature Range	-40°C ~ 60°C (-40°F ~ 140°F)
Height	178mm	Operating Relative Humidity Range	8% ~ 90% (non-condensing)
Depth	650mm	Non-Operating Relative Humidity Range	5% - 95% (non-condensing)
Packaging
Gross Weight		Power Supply
Available Color	Steel	Support 2U standard power supply or redundant power supply.

Expansion Slots		Front Panel

• 7x Full-height		Buttons	Power On/Off button
			System Reset button
Drive Bays			USB2.0(optional USB3.0).
			UID button
HDD Bay	36x3.5" hot-swap SATA/SAS drive bays,built-in	LEDs	Power status LED
	2x2.5" drive bays.		HDD activity LED
	Anti-EMI design,compatible with 2.5"/3.5" HDD.		NIC LEDx2,UID LED
			Fan Fail LED,PWR Fail LED,
SAS / SATA Backplane

6Gb/s backplane(Optional 12Gb/s),compatible with SATA/SAS HDD, with temperature control chipset.		Power Supply
		Support 2U standard power supply or redundant power supply.
Peripheral Drives

DVD-ROM	Slim DVD-ROM Drive (optional)
