5gallons and 3 gallon Washer Filler Capper

It is the ideal equipment for mineral water, distilled water and purified water producing process. This machine composed with rinse filler and capper, adopt cylinder cap press, with cap return function, cap sorter can keep one hour cap consummation, rinsing pressure will be displayed,
The main electrical parts adopt products with brand of SIEMENS and OMRON. Pneumatic parts adopt products with brand of AIRTAC. Both the inner and outer shower nozzle for washing barrel adopts the special technology equipment from American Sprayer Company. The machine works reliably and efficiently based on the compact structure and high automatic technology. It is the fully automatic barreled water producing equipment combined with machine, electronic and pneumatic components.

used for 3gallon and 5 gallon
5gallon barrel filling machine
5 gallon filling machine
5 gallon production line

Main technological data

Model	QGF-100	QGF-200	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200
Filling heads	1	2	3	4	4	6	8
Volume(L)	18.9	18.9	18.9	18.9	18.9	18.9	18.9
Barrel size(mm)	270*490	270*490	270*490	270*490	270*490	270*490	270*490
Capacity(b/h)	100	200	300	450	600	900	1200
Gas Pressure(Mpa)	0.4-0.6	0.4-0.6	0.4-0.6	0.4-0.6	0.6	0.6	0.6
Gas consumption	0.37	0.37	0.6	0.8	1	1.5	1.6
Power (kw)	1.38	1.75	3.8	3.8	7.5	9.75	13.5
