6-LED Recessed Underwater light_Lighting_Consumer Electronics & Lighting_Products

Top Selling

品牌：: comlite

Model: cl-wl6

Origin: Made In China

Label: underwater lights , led lights , led lamps

Features

1. This high-power LED fixture is all made of stainless steel and must be installed underwater.

2. Excellent design of heat-conducting housing ensures long life time of LED.

Specifications:

Housing:	Molding shaped 304# stainless steel housing
Glass:	Step tempered glass T=8mm
Loading capacity:	Exert force area of Φ10=660kgs,Φ30=1840kgs
Lens:	Asymmetrical optical lens, efficiency ≥85%
Cable gland:	IP-68 PG-11 copper and nickel coated
Waterproof seal:	Molding shaped silicone double seal
LED:	High Power LED 6pcs
PCB:	Excellent heat conductivity aluminum, coefficient of heat conductivity ≥ 2.0w/mk
Driver:	constant current output Single color LED=1-circuit output RGB 3 in 1 LED =3-circuit output
Application environment:	In normal temperature water, water depth: within 1 meter
Power cable:	H05RN-F 2x1.0m㎡ L=3m (for single color) H05RN-F 4x0.75m㎡ L=3m (for RGB)
Mounting sleeve:	ABS plastic

Remarks:

1. LED driver is customized when the circumstance of working temperature is below 0℃

2. Use only switching power supply or coiled transformer for 24VDC power input.

3. Customized 316# stainless steel is available.

Dimension:

Technique Parameters:

B4Y0602	6X3W	30°	24VDC	625	15	Cool white=545 Warm white=490
B4Y0606	6X3W RGB 3in1	30°	24VDC	R=175	R=4.2	R=131
				G=312	G=7.5	G=255
				B=315	B=7.5	B=60
C4Y0602	6X3W	______	24VDC	625	15	Cool white=545 Warm white=490
C4Y0606	6X3W RGB 3in1	______	24VDC	R=175	R=4.2	R=136
				G=312	G=7.5	G=258
				B=315	B=7.5	B=63

Part No.

Light Source

Lens Beam Angle(°)

Input Voltage(V)

Operating Current(mA)

Consumption(W)

Luminance
(lm)

Advantage:

1. Beautiful appearance design
2. Long lifespan >50,000 hours
3. Low working voltage, safe for humen
4. Green Light, environmental protection
5. Low power consumption, high efficiency, economic
6. Single color, R/G/B and RGB 3 in 1 are available
7. CE and RoHS approval, IP68
