AG-29 Magnetic Cylinder Sensor

Model

AG-29DF

AG-29N

AG-29P

Switching Logic

Normally Open

Solid State Output, Normally Open

Output Type

2 Wire Solid State

NPN Current Sinking

PNP Current Sinking

Voltage Range

10～30V DC

5～30V DC

Sensor Current

1～50 mA

0～100 mA

Switch Rating

1.5 W Max.

3 W Max.

Consumption

/

3 mA Max.@24V

Voltage Drop

2.65V Max.@50mA DC

0.5V Max.@100mA DC

Leakage Current

90 μA Max.@28V

0.01 mA Max.

Indicator

Red LED

Red LED

Green LED

Cable

Φ2.8, 2C, Grey Oil-Resistant PVC

Φ2.8, 3C, Grey Oil-Resistant PVC

Sensitivity

40～800 Gauss

40～800 Gauss

Sensor Frequency

900Hz

900Hz

Temperature

-10～70℃

-10～70℃

Shock

50G

50G

Vibration

9G

9G

Ingress Protection

IP68 (GB/T4208-2017)

IP68 (GB/T4208-2017)

Protection Circuit

Surge Suppression

Power Reverse Polarity; Surge Suppression

CE Certificate NO.

E8A 17 04 53334 007

E8A 17 04 53334 008

CNEx Certificate NO.

CNEx21.2238X

CNEx21.2239X

RoHS2.0 NO.

RoHS 2011/65/EU & (EU) 2015/863

Reach NO.

(EC) N 1907/2006 (REACH)
