Acoustic High Partition Walls for Multi-Purpose Hall and Conference Room_Prefabricated Building_Construction & Decoration_Products

Top Selling

品牌：: DALAI

Model: 65

Origin: Made In China

Label: movable partition , Active partition , Mobile partition

Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Specification						Carrier
Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Thickness (mm)	Width(mm)	Height(mm)	Top Seal(mm)/ Pressure(kg)	Bottom Seal(mm)/ Pressure(kg)	LCP stretch (mm)	Carrier
DL65-32	22	60	32db	65	680-1212	2000-4500	22.5/35	22.5/35	140	65#
DL 65-38	27	60	38db	65	680-1212	2000-4500	22.5/35	22.5/35	140
DL 65-45	35	60	45db	65	680-1212	2000-4500	22.5/35	22.5/35	140

Technical data of Type 80 movable partition :

Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Specification						Carrier
Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Thickness (mm)	Width(mm)	Height(mm)	Top Seal(mm)/ Pressure(kg)	Bottom Seal(mm)/ Pressure(kg)	LCP stretch (mm)	Carrier
DL 80-40	30	60	40db	80	680-1212	2000-5500	22.5/35	22.5/35	140	80#
DL 80-45	38	60	45db	80	680-1212	2000-5500	22.5/35	22.5/35	140
DL 80-48	47	60	48db	80	680-1212	2000-5500	22.5/35	22.5/35	140

Technical data of Type 100 movable partition :

Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Specification						Carrier
Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Thickness (mm)	Width(mm)	Height(mm)	Top Seal(mm)/ Pressure(kg)	Bottom Seal(mm)/ Pressure(kg)	LCP stretch (mm)	Carrier
DL 100-43	38	60	43db	100	680-1219	2000-7500	30/40	30/40	140	100#
DL 100-48	46	60	48db	100	680-1219	2000-7500	30/40	30/40	140
DL 100-53	55	60	53db	100	680-1219	2000-7500	30/40	30/40	140

How to select the suitable movable wall for your site?

We have 5 types of movable wall , 65type , 80type , 100type and 125 ultra-high type . You can choose the right

movable wall upon the Height and Soundproof requirement as following,

65 type— Max height 3.5m, soundproof: 38dB to 43dB

80 type— Max height:5.5m,Soundproof: 43dB to 53dB

85 type— Max height:5.5m,Soundproof: 43dB to 53dB

100 type— Max height:7m,Soundproof: 43dB to 58dB

What you should do on site ?

A beam(truss) should built on site for track installation . The min distance leaving for track installation from false

ceiling to top ceiling is 200mm .

How to install ?

We will provide the installation manual and video guiding the installation job . We can also dispatch the installation

engineer supervising the installation as request .

What is lead time ?
The lead time is 7 days to 10 days .

How to transport ?

Sea transport is a common mode of transportation. In an emergency, can be air freight.

How do the goods packing ?

Corrugating paper packaging, MDF batten cover all around corner .

The movable wall panel and track, fittings will be packed separately .

What is Procurement procedure ?

Firstly , send us the shop drawings(if the shop drawings is not available , you can tell us the height from false ceiling

to finished floor and width from wall to wall)

Secondly , we offer you the movable wall layout drawings for your /confirm/iation

Thirdly , we quote the movable wall in accordance with confirmed drawings .

Contacts

Company Name: Foshan Dalai Partition Co., Ltd.

Name:: Mr. peter

Telephone: 86-18676555455

Address

Operational Address: No. 26 Xinlian Industrial Zone, Tancun, Lishui Town, Nanhai District, Foshan City
