BioHub MIX Single-use Desktop Mixing System

The small size design is equipped with a unique paddle to meet the mixing of small volume of material and liquid.

Please be advised that this product is only available for sale and after-sales support in certain regions. For further details, kindly consult with your local sales representative. Thank you for your understanding.

Features of BioHub MIX Single-use Desktop Mixing System

Volume range: 560mL-22L

The whole machine adopts 304 stainless steel polishing design, Ra≤0.8μm, no damage to the soft bag body

The unique paddle design makes the material liquid even in a small volume

8AAD5

Small-volume design, can be placed on the desktop to easily achieve mixing of material and liquid.

Modular design, pH, cond, temperature, weighing, peristaltic pump, printer, etc. can be selected according to needs

Details about BioHub MIX Single-use Desktop Mixing System

The BioHub® Series Single-use Desktop Mixing System works through a magnetic coupling motor to drive the single-use stirring paddles in the mixing bag to rotate, and is equipped with physical shaft seals. This system is safe, reliable, stable and efficient. Working together with a stainless steel bin, it can meet liquid-liquid mixing and solid-liquid mixing needs, and suitable for various small-volume mixing applications, such as medium preparation, buffer preparation, intermediate mixing, semi-finished product mixing, and final pharmaceutical product mixing.

The mixing system consists of a stainless steel bin, a control system, a magnetic mixing motor, and a  single-use mixer bag. The modular design allows for flexible combinations of different functions on demand, such as mixing, weighing, feedback-controlled temperature monitoring, pH, and conductivity, while supporting high levels of customization to the complex needs of customers. The system also provides three-level permissions and data export to meet the data integrity needs of pharmaceutical customers.

We provide laboratory mixers agitators, laboratory mixer stirrer, laboratory magnetic stirrer mixer, electric lab mixer, electric stirrer lab, high speed lab mixer, lab magnetic mixer, lab mixer homogenizer, etc. For more about bioprocess engineering, contact us.
