Double Element Ground Screw Yard Anchor

Element Ground Screw introduction：

1. Outer diameter: 76mm

2. Length: 1600mm 1800mm 2000mm 2500mm

3. Wall thickness of the pipe: 3.0mm 3.25mm 3.75mm 4.0mm

4. Diameter of the spiral：156mm 176mm 196mm 236mm 250mm

5. Thickness of the spiral: 3.0---6.0mm

6. Material: Q235

7. Surface treatment: Hot Dip galvanized

8. Connect style: 3*M16 nuts

9. Packing: Steel pallet and wrap film

Element Ground Screw Description

The Element Ground Screw is crafted from high-strength Q235 carbon steel and finished with a precise hot-dip galvanization process, offering superior corrosion and weather resistance. The spiral design ensures a secure anchor in various ground types. Its robust structure and durability come in multiple sizes to meet diverse needs, providing reliable stability and support for a variety of foundation applications.

Product Features

High-Strength Q235 Carbon Steel: Built from Q235 carbon steel, known for its impressive tensile strength and excellent resistance to bending and pressure, ensuring stable ground support.

Precision Spiral Design: The well-defined spiral structure facilitates quick installation and enhances grip and stability when embedded in the ground.

Corrosion Resistance: With a hot-dip galvanized finish, it offers excellent anti-rust performance, enabling long-lasting durability even in harsh outdoor conditions.

Versatile Compatibility: Designed for use on a wide range of ground types, including soil, gravel, and even certain concrete surfaces, making it adaptable for various application needs.

Product Advantages

Easy Installation: Requires no digging or concrete pouring, saving both time and effort. Installation is quick and efficient with basic tools, greatly reducing project completion time.

Durability: The solid material and exceptional oxidation resistance ensure longevity in outdoor settings, reducing maintenance costs over time.

Eco-Friendly: No ground excavation is required, minimizing environmental disruption and leaving the surrounding area intact.

Adaptable to Multiple Climates: Whether exposed to coastal humidity or extreme temperatures, the Element Ground Screw maintains excellent resilience and functionality.

Applications

The Element Ground Screw is ideal for a wide range of outdoor applications, such as solar panel mounts, outdoor signage, wooden decks, fencing systems, and lightweight building foundations. With outstanding ground-holding capacity and adaptability, it is widely applicable in construction, agricultural, commercial, and residential projects, providing stable foundations for diverse outdoor structures.
