Application:
Indoor FTTH;
For patch cords and pigtails;
For communication equipment.
Feature:
Good mechanical and environmental characteristics;
Flame retardant characteristics;
Cable jacket options:PVC,LSZH,PE
Strength Member options:Steel,FRP,KFRP.
Mechanical Characteristics:
Tensile Strength | Long Term | 80N |
Short Term | 150N | |
Crush Resistance | Long Term | 100N/100mm |
Short Term | 500N/100mm | |
Bending Radius | Dynamic | 20XD |
Static | 10XD |
Optical Characteristics:
|
| G652D | G657A1 | G657A2 | G.655 | 62.5/125 | 50/125 |
Attenuation | @850nm |
|
|
|
| ≤3.0dB/km | |
@1300nm |
|
|
|
| ≤1.0dB/km | ||
@1310nm | ≤0.36dB/km |
|
| ||||
@1550nm | ≤0.22dB/km | ≤0.23dB/km |
|
| |||
Bandwidth | @850 |
|
|
|
| ≥500MHZ·km | |
@1300 |
|
|
|
| ≥600MHZ·km | ≥1000MHZ·km | |
Numerical Aperture |
|
|
|
|
| 0.275±0.015NA | 0.200±0.015NA |
Cut-off Wavelength |
| ≤1260nm | ≤1480nm |
|
| ||
