Product Parameter | Parameter Description |
Fail Safe | Lock when energized |
Face Plate | 150Lx25Wx37H(mm) |
Bolt | 16mmDIA,stainless steel 13mm throw |
Voltage | DC12V(DC24V) |
Start Current | 960mA |
Standby Current | 180mA |
Solid Bolt | polishing housing, 1000Kg Holding Force |
Suitable For | Electric Bolt For Narrow Door |
Signal Output | Door status Output,NO/COM |
Surface Temp | Low Temperature |
Induction Distance | 8mm |
Operating temp | -10～+55℃(14~131F) |
Operating Humidity | 0～90%(non-condensing) |
Special Designed | Tested to 500000 operations |
Face place material | Stainless Steel |
Weight | 1.06kg |
