GPS Active Antenna with screw

         Model : BY-GPS-06-01

（i）Dielectric AntennaCenter Frequency（MHz）：1575.42±3VSWR：1.5:1Bandwidth（MHz）：±5Impedance（Ω）：50Peak Gain ＞3dBi  based on 7cm×7cm ground planeGain Coverage ＞-4dBi at –90°＜0 ＜+90°(over 75% Volume)Polarization：RHCP （ii）LNA/FilterLNA Gain (Without cable) ：28 dBi TypicalNoise Figure（dB）：1.5Filter Out Band Attenuation (f0=1575.42 MHz)7dB Min f0+/-20MHz;20dB Min f0+/-50MHz;30dB Min f0+/-100MHzVSWR ＜2.0DC Voltage（V）：2.7/3.0/3.3/5.0/3.0 to 5.0 etc.DC Current （mA）：11 Max （iii）MechanicalWeight（gram）＜110Size（mm）：Φ46 ×14.5Cable Length（m）：withoutConnector：TNC femaleMounting：Screw mountHousing：Black（iv）EnvironmentalWorking Temp：-40℃~+85℃Storage Temp：-45℃~+100℃Vibration：Sine sweep 1g(0-p)10~50~10Hz each axisHumidity：Humidity95%~100%RHWeatherproof：100%Waterproof

        -------------------------------------------------------------------------------------------------
