- 品牌：
- HONGLI
- Model
- 1P/40A-480VAC
- Origin
- Made In China
- Label
- AC Contactor , Contactor , DP Contactor
1 、Application HLC-1PH04GG definite purpose contactors (1-pole ,40A/480V ) are ideal for（HVAC） air conditioning, refrigeration, heating, data processing, welding, elevators, hoists & cranes, lighting, pools & spas and food service equipment. | 2 、Ordering information |
| HL | C | - | 1P | H | 04 | GG | | Hongli Electric | Contactor | Factory Bulk Pack | 1P | 480VAC | 40 FLA | #14-4 Lug with quad QC |
|
Product Feature |
| Detailed Product Description | • Unique amortization system to eliminate contact bounce | | • Low cost | | • Accessories modification quickly and easily without using tools | | • Various kinds of terminals for customers' special requirements | | • Easy to change the coil | | • General amounting size, easy for replacement | | • Can be combined with a thermal overload relay to form an electromagnet starter to protect the line in which overload operation may occur | | • Double E magnet assembly providing optimal performance with reduced power consumption | | • Effective dustproof cover available | | • Silver Cadmium Oxide contacts provide long electrical endurance. | | • Class F high temperature insulated coils are standard. |
|
Technology Data |
NUMBER
OF
POLES | COIL
VOLTAGE
50/60HZ | FULL
LOAD
AMPS | LINE
VOLTAGE | LOCKED
ROTOR
AMPS | RESISTIVE
SMPS
RATING | MAXIMUM HORSEPOWER | BOX
QUANTITY | APPROX
UNIT
WEIGHT | | VOLTAGE | SINGLE
PHASE | | 20FLA-2POLE | | 2 | 24
120
208/240
277 | 20 | 240/277
480
600
| 120
100
80
| 30
30
30 | 120
240 | 2
3
| 50 |
.27 kg | | 25FLA-11/2&2POLE | 1
with shunt | 24
120
208/240
277 | 25 | 240/277
480
600
| 150
50
40
| 30
30
30
| 120
240
| 1
2
| 50 |
.23 kg | | 2 | 24
120
208/240
277 | 25 | 240/277
480
600
| 150
125
100
| 35
35
35
| 120
240
| 2
3
| 50 | .27 kg | | 30FLA-11/2&2POLE | 1
with shunt | 24
120
208/240
277 | 30 | 240/277
480
600
| 150
75
50
| 40
40
40
| 120
240
| 1
2
| 50 | .23 kg | | 2 | 24
120
208/240
277 | 30 | 240/277
480
600
| 150
125
100
| 40
40
40
| 120
240
| 2
3
| 50 | .27 kg | | 40FLA-11/2&2POLE | 1
with shunt | 24
120
208/240
277 | 40 | 240/277
480
600
| 240
200
160
| 50
50
50
| 120
240
| 2
3
| 50 | .23 kg | | 2 | 24
120
208/240
277 | 40 | 240/277
480
600
| 240
200
160
| 50
50
50
| 120
240
| 2
3
| 50 | .27 kg |
| OTHER SPECIFCATIONS | 20-35 FLA | 40 FLA | | Line and Load Terminals | #10-32Screw* | BoxLugs* | | Wire Size Awg Min-Max | 16-8* | 14-4Cu/Al | | Tightening Torque(recommended) | 25in.Ibs | 40 in.Ibs | | Coil Termination | Dual.250 QC(2) | Dual.250 QC(2) | | Quick Connects.250 std.-1 or 11-2 Pole | Quad | Quad | | Quick Connects.250 std.-2 Pole | Dual or Quad | Dual or Quad | | Covers | Optional | Standard | | Insulation System | 130℃ Class B | 130℃ Class B | | *stranding must be split for #8 wire*Permissible Ambient Temperature: -40℃/65℃ -40F/150F |
| COIL TECHNICAL DATA 50/60hz | 1POLE CONTACTORS | 2POLE CONTACTORS | | Nominal Coil Voltage | 24 | 120 | 208/240 | 277 | 24 | 120 | 208/240 | 277 | | Maximum Pickup Volts | 18 | 88 | 177 | 221 | 18 | 88 | 177 | 221 | | Drop-Out Volts Range | 6-15 | 20-70 | 40-140 | 50-165 | 6-15 | 20-70 | 40-140 | 50-160 | | Nominal Inrush VA@50Hz | 31 | 31 | 35 | 31 | 22 | 22 | 22 | 22 | | Nominal Inrush VA@60Hz | 28 | 28 | 32 | 28 | 20 | 20 | 20 | 20 | | Nominal Sealed VA@50Hz | 6 | 6 | 7 | 6 | 5.5 | 5.5 | 5.5 | 5.5 | | Nominal Sealed VA@60Hz | 5 | 5 | 6 | 5 | 4.5 | 4.5 | 4.5 | 4.5 | | Nominal DC Resistance-Ohms | 17.5 | 450 | 1800 | 2252 | 13 | 275 | 1056 | 1772 |
|
Specification |
| HLC-1P,1N,1X,2X,3X,4X series Difinite Purpose Contactor | | DownLoad PDF DataSheet |
|
