Hospital Privacy Curtain

Hospital Cubicle Curtain & Track

Hospital Cubicle Curtain

Hospital cubicle curtain is hung around hospital beds in multiple- or single- bed wards to maintain patient privacy and therefore, is also called privacy curtain.

  Hospital cubicle curtain fabric is required to beflame-retardant. LONGWAY’s curtain fabric is made of flame-retardant fiber and the feature is inherent, which means it does not fade away after washing. Tests show that the fabric totally complies with BS 5867-2:2008 Type C performance requirements. The feature remains well after 50 cycles of standard washing (in accordance with BS EN ISO 10528: Automatic machines (Tyep A) at 75+/-3 deg C in ECE detergent with sodium perborate, tumble dry). It can also well meet NFPA 701 flammability requirements. Anti-microbial feature is also available. Relative tests are in accordance withAATCC 147-2004 standard.

LONGWAY’s Standard fabric weight is around 220g per square meter. It can also be raised up to around 270g per square meter. Usual vertical length is 2.8m, including a 50-60cm top mesh to meet and/or exceed fire codes for fire sprinkler penetration. The mesh part also enables free air flow and light ventilation throughout the patient room.

Curtain Track and Accessories

LonGWAY curtain track is made of well oxidized aluminum alloy. It can be straight, L-shaped or U-shaped for enclosing patient beds, shower areas or anywhere personal privacy is required. L-shaped curtain track is usually used for multiple-bed wards and U-shaped ones for single-bed patient rooms. Tracks of white baked enamel finish are also available to match with white ceiling and walls.

  Accessories for curtain track include end stop, pulley/glide, hook and splicing clamp. Each set of curtain track requires a pair of end stops. Usually 5 pulleys and 5 hooks are needed for each meter of track. Splicing clamp is used for U-shaped track as it is usually divided into two halves for delivery convenience; or it can also be used for connecting two straight tracks to make a longer one.

  LW-TK-20 Curtain Track: 23mm*18mm*1mm

  LW-TK-30 Curtain Track/ IV Pole track: 30mm*20mm*1mm
