ISUZU Truck Diagnostic Scanner Isuzu Tech2 Full Set V170 Heavy Duty tool

ISUZU Heavy Duty Truck Diagnostic Scanner Isuzu Tech2 Full Set----software version V169

 MSN: jiutech9705@hotmail.com

Skype: jiutech9705

We Chat: heyan-918

whatsapp: +8613631686452

Software V170 ISUZU TECH 2 Diagnostic Software 32MB Cards

Software version : V170, from 2006 to 2017 latest

Package List:

Isuzu Tech2 full set*1
Isuzu 24V adatper for truck test*1
32mb software card: V1690*1 ( from 2006 to 2017)

Hard Case*1

ISUZU Tech-2 is the same tester GM Technicians use to diagnose ISUZU vehicles. The Vetronix Tech 2 comes with Authentic GM software and provides support for on-board diagnostics on all ISUZU systems 1992 to 2017
Features:
Authentic ISUZU software in the Tech 2 Flash means the most comprehensive diagnostic software available for late model ISUZU vehicles.
Support for on-board diagnostics on all ISUZU systems 1992 thru current year.
Removable hardware modules provide insurance against scan tool obsolescence.
Large, easy-to-read backlit screen.
RS232 & RS485 ports provide the avenue to connect future devices to your Tech 2 Flash.
Ability to capture stored DTCs, Freeze frame, and Failure Record for later review.
Ability to view the status of vehicle diagnostic tests as they run.
Bi-directional
The authentic ISUZU 1992-current year software will provide full bi-directional control when performing power train, chassis, and body diagnostics.

ISUZU Tech-2 Specifications

Dimensions
 12″×6″×2″

Microprocessor
 32 bit, 16 MHz

Memory
 32 MB flash type II PCMCIA. Type III slot available for future expansion.

Communications
 Integral RS232 communication port.

Screen
 3.8″×2.8″ backlit monochrome with full graphics capability: 320×240 pixels. Displays up to 9 vehicle parameters at once
ISUZU Tech-2 Starter Kit with Candi Module & TIS Kit includes :

Tech-2 Flash Tester
32 MB PCMCIA Card with ISUZU OE Applications
CAN diagnostic interface module(CANdi) and instruction sheet download ( 199.2 kb )
GM aftermarket Expertec TIS software on DVD-ROM disks
Data/Sensor/Trouble Code Manual
DLC Cable, DLC Loopback Adapter
12V Cigarette Lighter Power Cable
SAE 16/19 Adapter
NAO 12/19 Adapter
Battery Power Cable
Storage Case
Tech-2 Users Manual

An industry change in protocol from OBD II to Controller Area Network (CAN) has begun. In order to perform diagnostics on a vehicle that uses the CAN interface; you will need the Tech 2 Flash and a CAN diagnostic interface module. The module connects between the Tech 2 Flash’s diagnostic link cable and the OBD adapter. once the module is connected, it can be used on all Isuzu vehicle applications, even those vehicles using other platforms such as OBD I and OBD II.
