JW-GY71 NDT Integrated Rebar Scanner Laser positioning Deep Concrete Scanner
Features:
investigation depth could reach 180mm
Single comprehensive probe
Peak scanning
Automatic identification of rebar positions
Laser positioning
Automatic reading spacing of bars
Machine software is complete.The report could be printed automatically connecting with computer
Grid scan of the rebar position
Profile scan of the rebar position
| Technical Specifications | |||
| Bar diameter application range(mm) | Φ6 - 50 | ||
| Maximum permissible error of Bar diameter | ≤±1 | ||
| Cover thickness measuring range | |||
| The first measuring range (mm) | 6 - 90 | ||
| The second measuring range (mm) | 7-180 | ||
| The maximum error of cover thickness | |||
| The first measuring range (mm) | The second measuring range (mm) | Accuracy | |
| 6 - 59 | 7 - 79 | ≤±1 | |
| 60 - 69 | 80 - 119 | ≤±2 | |
| 70 -90 | 120 - 180 | ≤±4 | |
| Standard Delivery | Optional Accessory | ||
| Main unit, Software | 1 | Scan car | |
| USB connecting cable | 1 | Car cable | |
| Power charger | 1 | ||
| Manual | 1 | ||
| Warranty card | 1 | ||
| Carry case | 1 | | |
