KU Band Maritime VSAT VS80

BIRDSAT's new 80 cm ku band vsat  is on board now. Higher reliability, lower cost and easy plug-in operation, staying connected with your family, friends and business partners, enjoying normal communication, entertainment and business, the idea is making offshore life easier, more convenient and more cost effective.

Features of VSAT KU Band Frequency Maritime VSAT VS80

Less signal loss, more integrated module

With modem integrated inside the radome, the signal transmission loss has been significantly decreased.

Simplified installation

With a patented design of shipborne bracket, there's no need to dismounting the radome before installation. One outdoor cable combined with TX, RX and DC power cables all together connects to the radome base directly, and makes cost effective and simplified installation.

Plug & Play

BIRDSAT lnb buc vsat  antenna is user friendly, with built-in satellite recognition unit, just power on and the antenna will lock the satellite quickly and precisely without any extra manual configuration.

Higher wave transmittance, higher strength

By using GFRP material radome, the wave transmittance has been increased and the capability of wind resistance has also been increased.

Specification of KU Band Maritime Satellite Terminals VSAT VS80

Radome Dimension Reflector Diameter

104x110 cm (40.9x43.4 inch) 80 cm (31.5 inch)

VSAT Weight RX Frequency

75 kg / 165.3 lbs 10.7~12.75 GHz Ku-band

RX Gain TX Frequency

40.4 dBi @ 11.75 GHz (excl. radome) 13.75~14.5 GHz Ku-band

TX Gain G/T

38.6 dBi @ 14.25 GHz (excl. radome) 17.6 dB/K

Now the ku band antenna price is affordable, if you have needs, please leave us a message.

As a professional vsat internet provider, we can offer kinds of vsat terminal equipment for sale, more details, please contact us.
