LED emergency power supply 168H for 18W 90min full power LED lamp

LED emergency power supply DF168H for 18W-25W LED fluorescent lamps

luorescent lamp emergency power supply 18W-168H, full power emergency lighting power supply 90-180 minutes
LED emergency power supply 168H, used for 3W-25WLED fluorescent lamps, panel lights, LED floodlights, LED industrial and mining lights and other emergency power supply wide voltage settings, universal worldwide.
Isolated power supply, IC charging management, SAA and other safety certifications.
High-quality lighting emergency power supply, comparable to imported quality.
Large exports to Europe, America, Australia, Hong Kong and other places.
Both external and internal LED light sources can be used.
Allows one set of emergency power supply to match multiple LED lamps, and the total power must be between the range
Use with high temperature resistant lithium battery LIR and other rechargeable battery packs, digital circuits are strictly prohibited from using nickel battery packs;
International lines, thin film PC board three-color indicator light detection switch is safe and beautiful. Automatically switch working status.
100% full power emergency lighting after power outage, the same brightness as city power lighting.
The emergency power supply has multiple protection functions:
A Charging protection, after charging saturation, it automatically switches to trickle charging state to compensate for battery self-discharge;
B Discharge protection, during emergency lighting, when the battery power is exhausted, the discharge lamp will automatically end and turn off;
C No-load protection, during emergency lighting, if the lamp is damaged or taken away manually, the circuit will automatically return to zero and no longer work;
D Short circuit protection, self-recovery function.
E Self-test function, no manual inspection of emergency lighting function.
Connect the circuit strictly according to the wiring diagram, and do not open the cover at will;
Technical parameters:
Input: AC 100V-270V 50HZ Output: AC /DC 80-280V
Power: 18W-25W Emergency time: set according to customer requirements;
Battery: DC12V Charging current: 200mA
Length, width and thickness = 168*38*28mm Weight = 350g
The overall emergency power supply box size is customized, subject to the specification.
