Mini Crawler type Dumper with lift container

Model

WL-350H

Engine

Kaijian diesel engine 192FB/13HP

Track grounding length

800 mm

Track gauge

500 mm

Track width

180 mm

Start type

Electric

Loading weight

350 KG

Gear box

(3+1) * 2  configuration high low

Drive speed

F 1.8-6.1/R1.8-3.6 km/h

Container size

1400x750x700 mm

Package size

2060x850x1430 mm

Overall size

1960x750x1280 mm

Net weight

532  KG

Ground distance

140 mm

Slope angle

20 degree

Lift height

600 mm

Control type

Hydraulic hand hold

Lift container /dumper

Hydraulic cylinder
