Monitor Terminal

141 Terminal Technical Data
Pitch: 2.54mm;
Nominal diameter :26-20AWG;
Rated load: 150V/7A;
Withstand Voltage: 1.5KV;
Strip length :9-10mm;
Insulation housing: PA66 V-0;
Terminal: Brass tin-plated;
Temperature: -40 ℃ ~ 110 ℃;
PCB hole size: φ1.4;
Median: 2P-30P
Manufacturer capacity: 10 million / month performance and advantages: Operation Method: depressed button to cut length of 9-10mm or more shares of the single-stranded wire (multi-strand wire need solder) can be fully inserted hole demolition methods : depressed the button. toggle can remove the wire Packing: Product normally do 2P-30P different digits, the number of 2000-6000PCS ordinary box Usage: electrical and electronic equipment, ballast, lighting, IT communications, alarm devices. Service: product quality, rigorous trials and tests, one-year replacement, lifetime warranty
