Multi Channel Syringe Pump

Accuracy

≤1%@100% stroke

Precision (Repeatability)

0.3％-0. 5％@100% stroke

Rated stroke (control steps)

30mm (12000 steps standard, 24000 steps OEM)

Linear Speed

0.017mm/s - 5mm/s (media: water)

Running time (stroke)

6s - 1765s (media: water)

Resolution

0.0025mm (1 step)

Actuator

Ball screw (Lead 1mm)

Max. piston drive

≥80N

Sub. piston drive

≥40N

ILS syringe

25μL, 50μL,100μL,150μL, 250μL,500μL,1ml,1.25ml, 1.5ml, 2.5ml, 3ml, 5ml

Valve model

M01 M02 M03 M04 M05 M06 M10

Valve drive

≤280ms (switch between neighboring ports)

Wetted material

Borosilicate glass, PTFE, PCTFE, Sapphire

Max. pressure rating

0.7Mpa

Valve connection

1/4-28UNF

Syringe connection

1/4-28UNF

Communication

RS232/RS485/CAN

Baud rate

RS232/RS485: 9600bps, 19200bps, 38400bps, 57600bps, 115200bps

CAN: 100Kbps, 200Kbps, 500Kbps, 1Mbps

Address ＆ Parameter setting

Communication

Power supply

DC24V/3.0A

Operating Temperature

5℃-55℃

Operating Humidity

<80% relative humidity, non-condensing

Dimension (L*W*H)

137*45*127mm

Net weight

1.44kg

ILS Syringe

25μL

50μL

100μL

150μL

250μL

500μL

1ml

1.25ml

1.5ml

2.5ml

3ml

5ml
