Multi-function animal feed crushing and mixing machine grinding and mixer

● Mill housing adopt HT150 cast iron molding in one time,Strong and durable.

● Rotor use Q235, 6mm High-quality steel.After the dynamic and static balancecorrection,low noise,stable running.

● Spray tungsten carbide alloy hammer, Wear-resistance, impack resistance.Service life is two times longer than the ordinary hammer.

● Self-priming type miller 60*10.5, power 7.5 kw, Speed 2970rpm, sieve platehole Ø3mm, moisture 12-14% grain materials, Capacity 1000-1200 kg/hour.

● Single or Double ribbons mixer is made of Q235 material, the thickness of the two sideplates is 10mm, and the thickness of the U type groove plate is 6mm.

● The machine body is composed of a double spiral belt and a top sprayingsystem, and the two ends of the shaft are sealed by packing to prevent leakageof both ends.

● Specially designed discharge mechanism, big opening and small openingdischarge, discharge material quickly, less residue.

● The mixing weight of each batch is 1000 kg, and the mixing time is 6-7minutes.

● Mixer motor power is 15KW, rotate speed is 34 rpm.
