Ni80cr20 Belt for Double Strip Coils Braking Resistor_Metallurgy & Mining_Metallurgy , Mining & Energy_Products

Top Selling

Ni80cr20 Belt for Double Strip Coils Bra
CN ¥39.77

品牌：: HUONA

Model: 0.08*145

Origin: Made In China

Label: NI80 , CR20NI80 , ALLOY BELT

Ni80cr20 Belt for Double Strip Coils Braking Resistor

Ni80Cr20 is a nickel-chromium alloy (NiCr alloy) characterized by high resistivity, good oxidation resistance and very good form stability. It is suitable for use at temperatures up to 1200°C,and hold a superior service life compared to Iron chromium alumium alloys.
Typical applications for Ni80Cr20 are electric heating elements in home appliances,industrial furnaces and resistors(wirewound resistors,metal film resistors), flat irons, ironing machines, water heaters, plastic moulding dies, soldering irons, metal sheathed tubular elements and cartridge elements.

Mechanical Properties of Nichrome 80 Flat Heating wire

Max Continuous Service Temperature:	1200ºC
Resisivity 20ºC:	1.09 ohm mm2/m
Density:	8.4 g/cm3
Thermal Conductivity:	60.3 KJ/m·h·ºC
Coefficient of Thermal Expansion:	18 α×10-6/ºC
Melting Point:	1400ºC
Elongation:	Min 20%
Micrographic Structure:	Austenite
Magnetic Property:	nonmagnetic

Temperature Factors Of Electrical Resistivity

20ºC	100ºC	200ºC	300ºC	400ºC	500ºC	600ºC
1	1.006	1.012	1.018	1.025	1.026	1.018
700ºC	800ºC	900ºC	1000ºC	1100ºC	1200ºC	1300ºC
1.01	1.008	1.01	1.014	1.021	1.025	-

Style of supply

Alloys Name	Type	Dimension
Ni80Cr20W	Wire	D=0.03mm~8mm
Ni80Cr20R	Ribbon	W=0.4~40	T=0.03~2.9mm
Ni80Cr20S	Strip	W=8~250mm	T=0.1~3.0
Ni80Cr20F	Foil	W=6~120mm	T=0.003~0.1
Ni80Cr20B	Bar	Dia=8~100mm	L=50~1000
