One Colour Automatic Round-Objects Screen Printer

This machine is only used for printing various round bottles in single colour. The thansmission structure advantaged designed, so the machine runs stable and to be operated flexibly. It is good
For printing materials of plastic, glass and metal etc. It is very reasonable for the comparing function with price, so the machine is widely used.
Automatic single color screen printer on standard round objects;
High efficiency, Feeding, corona treatment, loading and screen printing and UV drying all in one process.
online corona treatment.
Reliable PLC control & touch screen operation system.
Closed working system, well safety protection:
Promise of quality with SMC, FESTO pneumatic parts and Omron, Siemens Electric parts.
High quality aluminium alloy ensure light and r edization.

Main parts
1. MAIN MOTOR: SITI(Italy)
2. PLC: Omron(Japan)
3. SENSOR: Optex(Japan)
4...TOUCH SCREEN: Proface(Japan)
5. Switch: Schneider(France)
6. (CONTACTOR): (Schneider)(France)
7(RELAY): (Idec)(Japan)
8. (INVERTER): Omron(Japan)
9. (UV CURING)(Primarc)Britain
10. (PNEUMATIC): Festo(Germany)

Technical data
Printing Speed: Round 4000pcs / hr
Printing Size Dia 15 -50mm Length 20-200mm
Compressed Air 0.6MPa
Lp Gas 0.15MPa
Dimension Unit 1800 × 1100 × 1100mm
Feeder & Receiver 1060 × 280 × 250mm
Power: 220VAC1.5KW

Price Terms --FOB or CFR
Payment Terms --T/T or LC
Packing --Wooden case
Lead Time ---8days after confirm PO
SKU ---8sets
Standards Certificate--- CE
Cubic Meter--- 5.6
Gross Weight ---820kg
