PA 6.6 gf50 is a fiber-reinforced plastic made of Nylon 66 resin as a base material and 50% glass fiber as a reinforcing filler, and various processing aids be added to be used in injection molding products.
Typical Application of PA66 GF50 (A2011J)
PA66 50%GF HB grade is applied to the field of industrial product structural parts, requiring high strength, high toughness, high and low-temperature resistance, and commonly used as water valve diverter and blade of air outlet, mechanical gears and bushings.
Processing Detail of PA66 GF50 (A2011J)
Other Details of PA66 GF50 (A2011J)
Physical Property
Ash | (50.0% 1 ISO3451/1) |
Conditioned | 600°C*2h |
Density | (1538Kg/m3 1 ISO1183) |
Conditioned | 23°C |
Shrinkage Parallel Flow | (0.1-0.3 % 1 ISO294-4) |
Shrinkage Vertical Flow | 0.2-0.5% I ISO294-4) |
Mechanical Properties
Tensile strength (217.0MPa 1 ISO527) Conditioned | 5mm/ min |
Tensile Strain at Break (2.5% I ISO527) Conditioned | 5mm/min |
Notched Impact Strength (17.0KJ/m2 I ISO179 Conditioned | 1.0J |
Flexural Strength (354 MPa 1ISO178) Conditioned | 2mm/min |
Flexural Modulus (14263 MPa I ISO178) Conditioned | 2mm/ min |
Thermal Property
Melting Point | (260°C I ISO11357) |
Hot Deformation Temperature | (260*C I ISO75) |
Conditioned | 1.8MPa |
Flammability Class | (HB 1UL94) |
Conditioned | mm |
Injection Molding Conditions
Drying Temperature | 130°C |
Drying Time | 3h |
Cylinder Temperature | 290-310°C |
Nozzle Temperature | 290-310*C |
Tooling Temperature | 80-100*C |
* Molding conditions are just for reference, please make an adjustment based on the actual situation！
As a professional engineering plastic company, Anmei group has high-quality modified plastics for sale. Welcome to contact us if needed.
