PCI-E2SL 3G-SDI Input Capture Card, 2CH Input/2CH Loopout 1080P/60Hz Vmix

PCI-E2SL 3G-SDI Input Capture Card, 2CH Input/2CH output 1080P/60Hz Vmix / Xsplit / Vlc / Virtualdub / Vidblaster / Obs / non linear editing software Live Streaming Game Video Recorder Card

Shipment:Shipping free via HK-DHL, normally you will receive it 5-7 working days after send,
Tips:The DUTY do not include the price

Support SDK:C,C++,VB,Delphi,Builder,support GPU
base the  directshow , such as Flash media in-cord/ windows media in-cord/ OBS/ VLC/ Vmix/ MSHOW etc.

Used for video conference/ education / CT video photo capture / virtual studio / X-ray security inspection machine / live steaming / game steaming / medical live steaming etc



Supported OS
Windows
Windows 7/8/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2016 (X86 & X64)
Linux (support X86, X64 & ARM architecture)
Ubuntu 12.04/14.04/16.04/17.04/17.10 (X86 & X64)
CentOS 6.5/7 (X86 & X64)
Fedora 25/26/27 (X86 & X64)
Red hat 6.5 and above (X86 & X64)
Other Linux OS with kernel version 2.6.35 and above
Mac
OS X 10.9/10.10/10.11
MacOS 10.12/10.13


Supported APIs
Windows
DirectShow
DirectKS
Wave API/DirectSound/WASAPI
Linux
V4L2
ALSA


Supported Software
VLC
VirtualDub
OBS
XSplit
VMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software


Multiple Cards per System
Support for multiple cards pl ed to one system
On-board rotary switch to set card number, with 16 positions from 0 to F
System hardware device tree will display "01:PRO Capture AIO" when rotary switch is set to 1, and so on
The video and audio device names displayed in your software will include the card number (set by the rotary switch)
Multiple Capture Streams
Unlimited capture streams for any one input channel

Independent cropping, aspect ratio, color format, resolution, frame rate, de-interlacing and color adjustment settings for each individual stream

SDK

PRO Capture SDK for DirectShow for easy integration (Windows)
PRO Capture SDK for DirectKS for maximum flexibility & performance (Windows)

Windows Driver Tweaks

All options can be controlled by three levels of registry key:Global level, product level, and device level
Video, audio, crossbar filter names can be customized via registry keys

Firmware Upgrade

Multiple cards in one system can be upgraded simultaneously
Cards can be upgraded without a system power shutdown when it is not in use
Supports Safe upgrade
If power off or system breakdown occurs when the firmware is being upgraded, it will automatically restore to the initial version (only available for firmware version 1.21 and above)



If you want improve the capture card to fix your solfware please contact us the SKD, OEM is available , our video capture card include 1/2/3/4 CH HDMI and HDSDI slots.USB and PCI-e video capture cards
We also improve Trackless virtual studio system based this video capture card, supply studio equipment
