Sinotruk Howo 4*2 Dry Powder Combined Water Foam Tank Fire Truck for Manufacture

Sinotruk Howo Water Foam and Dry Powder Combined Tank Fire Truck

Sinotruk Howo Water Foam and Dry Powder Combined Tank Fire Truck, is modified with Sinotuck Howo ZZ5207TXFV471GE5 chassis, using D10.34-50 diesel engine, reaching Euro 5 emission standard, of 337 horsepower, steam brake, double row; The fire truck composes of three parts. The front part of the body is the equipment box (dry powder tank, nitrogen bottle, dry powder system), the middle part is the water tank, and the rear part is the pump room.

Main Technical Data

1. Dimentions & Weight

Length: 8880 mm

Width: 2496 mm

Height with body:3630 mm

Wheel base:5000 mm

Weight: 19450 kg

2.Chassis: ZZ5207TXFV471GE5

Engine Model: ISB190 50

Type: Vertical six cylinder, water cooled four stroke, supercharged medium cooling, electric controlled high pressure common rail engine

Power(kW): 248 (Horsepower: 337 hp)

Displacement (ml): 6870

Emission standard: Euro 5

Max Speed : ≥95 km/h

Gear Box: DongFeng six speed gearbox 5 forward speed range gearbox, one reverse speed.

Drive: Left Hand Drive/Right Hand Drive

Wheel drive: 6×4

Cabin: 4 door 6 human, 4 SCBA SHELF

Tires: 315/80R22.5,12.00R20

Color: Customized

Communication: FM/AM radio With USB

                           VHF radio with Microphone (optional)

Capacity:  Foam 1900 kg,  water 2800 kg, dry powder 2000 ml

Made of Carbon Steel

Electrical Level indicators

Pressure equalizer

Overflow valve

Fire monitor Top of the tank

Inlet filling: 2 by DN65, 2 by DN65

Drain: DN 25 mm

3. Fire equipment

Water monitor: Flow: 60 L/S, workheight: ≥70m

Foam monitor:  Flow: 48 L/S, workheight: foam≥50m water≥55m

Dry powder monitor:  Flow: 30 kg/s,  @1.4Mpa

Nitrogen gas cylinder: 6*70 L, recharging time: 45 s. A central air charging interface is provided
