TS7700

1、D / 8 geometric optical structure, conforming to CIE No.15, GB /T 3978, GB 2893, GB /T 18833, iso7724 / 1,ASTM e1164, din5033 teil7;

2、Adopt combined LED light source with high life and low power consumption, including UV / excluding UV;
3、Switchable 8mm &4mm aperture(the flat/ tip measuring aperture can be switched easily, which is suitable for more  tested sample)

4、Dual optical path system, the optical resolution in the visible range is less than 10nm, which can measure the SCI and SCE spectrum of the sample at the same time;
5、Accurate spectrum and lab data, used for color matching and accurate color transmission;
6、High hardware configuration: 3.5-inch TFT true color screen, capacitive touch screen, 1000 line blazed grating, silicon photocell array detector with large photosensitive area, etc;
7、USB / Bluetooth dual communication mode, wider adaptability;
8、Super dirt resistant and stable standard white calibration board;
9、Large capacity storage space, which can store more than 30000 pieces of test data

10、2/10 standard observer's angle, multiple light source modes, multiple surface color systems, meet various standards         of chromaticity indicators, and the needs of various customers for color measurement;
11、 Camera locating position and Stabilizer cross measurement position;
12 、 PCsoftware has powerful function expansion;

--------------------------------------------------------------------------------------------------------------------------------------

APPLICATION INDUSTRY
It is widely used in plastics, electronics, paints and inks, textile and garment printing and dyeing, printing paper, automotive, medical, cosmetics and food industries, scientific research institutions and laboratories.The instrument can accurately measure multiple color indices such as reflection spectrum in multiple color spaces.With this instrument, research on color matching, color management, etc. can be easily performed, and precise product quality management control can also be performed. The instrument is equipped with high-end color management software, which can be connected to a computer for more functions.
