Three in one tank pumping filtering aeration brushless DC submersible pump

No need for maintenance, small volume and high efficiency, low power consumption,strong anti-interference ability, stable running.

No brush, no pollution, long service life of the electronic commutation.

Damping silicone, shock absorption, noise reduction, silica gel position adjustable,convenient installation.

The stator and the circuit board part by epoxy resin and is completely isolated fromthe rotor, solves the problem of leakage of motor DC pump long-term divinggenerated, completely waterproof.

To solve a series of problems of water pump in the complex environment appeared in the death card, the pump suddenly don't start.

Pump optional water protection, protecting, blocking protection, the death cardprotection function.

According to the requirements of modulation parameters of pump, 12V pump can be modulated 1 meters head, also can be 3 meters lift, constant volume, wide voltage operation.

To solve the problem of water pump driven by mortality, currently on the marketwater pump mortality was about 2%~3%. After a long time study research will pumpmortality decreased to less than 5/10000.

Such as the need to increase the pump head can also pump series, then lift double.

Amphibious (position below the surface mounting external use).

Can be customized according to the design of pump and related control systemsuser requirements.

Brushless DC pump use matters needing attention:

1 brushless DC pump performance, the premise is the correct use, the use of the environment would influence the actual effect of the water pump;

2 pump according to different customers different needs of wire joint variety, pleasepay attention to buy their product page description and the Advisory service;

3 brushless DC pump can not use of overpressure, please use the correspondingrated voltage DC power supply for water pump power supply;

4 brushless DC pump is a centrifugal pump, the air, can not discharge can not automatically self absorption, must be installed below the liquid level can be used in;

5 impurities and particles into the pump experience damage the water pump, please ensure that clean water sources, with particular attention to use, recommended retrofit filtering device;

6 pump must not dry (anhydrous idle), long time of anhydrous air transfer burnedwater pump;

7 pump used in the pipeline, first open the valve and then turn on the power supply,closed the first cut off the power and then close the valve;

Adapter cannot be 8 general router and the Internet as the pump power supply cat,the AC component is more, easy to burn the motor;

9 batteries can not be directly connected to the pump, the battery is full of the later actual voltage will be far more than its rated voltage, must be added to the pressure limiting measures connected to the pump;

10 the lift pump does not refer to the spray height, but refers to the vertical height of water after the water feeding;

11 pump at maximum lift when the flow rate was 0, please refer to diagram flow liftpump selection;

12 pump is our life in the laboratory test results of stable working environment,different use of the environment may shorten the service life of the water pump;

13 to ensure the water clean, regular inspection can increase the service life of the pump;

14 If there is a need to consult us.

A power adapter (transformers) description:

The company sold pumps are brushless DC pump, next is the DC power supply 12v/24v, remember to not be directly connected with a 220V alternating current,must connect the power adapter can then home 220V alternating current, the company has the power adapter supporting, for customers to buy. The company sells with adapter pump, wire is generally DC head with international standards; if you buy water pump connector for bare wire, please note the positive and negativedo not reverse, (red for positive, negative black, please pay attention to the correctconnection), otherwise easily lead to burn the bad pump;

For further understanding the adapter, please see the following:

1 if you do not have the power adapter, it is recommended that you buy with powerpackage, we supply is zero profit sale price to sell, can only buy our pumpcustomers, maybe not the cheapest on the market price, but the quality has the highassurance, is our factory selected from numerous power adapter in the number ofsuppliers many can withstand the test of the supplier, you can go to the proper understanding about the behind the scenes plotting power adapter, second-handinferior chip + scrap cannot guarantee the safety of our water pump, also can't guarantee your safety.

2 if you have the following its own power, you are welcome to use my own power: (1)the adjustable DC regulated power supply; (2) the standard voltage of power supply module of industrial equipment, all kinds of electrical appliances directly provide; (3)the DC power source adapter is absolutely reliable quality.

3 please do not use the Internet Modem and router adapter or other inferior adapter,adapter filter Internet Modem and router is not clean, the AC component of many,very easy to burn the water pump; the use of battery power supply must be measured voltage in the battery is full of, can't use of overpressure, because of power problems customers own burned water pump, we can not guarantee thecustomer service, please understand!

Reminder:

1 brushless DC pump is a new type of water pump, if you don't know about that,please read our product information carefully and the use of attention;

2 brushless DC pump has the advantages of small volume, do not judge the qualityand cost of water pump in size, we a chip, a rotation shaft on the cost to AC pumppurchase a larger;

3 brushless DC pump has many advantages, one of the most intuitive is to use life,high lift and large pressure, and DC low voltage on the personal safety guarantee.More features please refer to the product details or consulting our;

4 brushless DC pump is not suitable for all occasions, durable is built on the premise of correct use, for example, you can't take the intelligent mobile phone with old-fashioned Nokia to more than who carry the fall. Method of use is too bad working environment or violence will cause the pump can not achieve the expected life;

5 of all water pump parameters can be customized, if demand please contact us, look forward to your cooperation,

6 a detailed understanding of the performance of the pump, such as working voltage,current, temperature, whether the amphibious (our products are centrifugal pump,self-priming pump, the medium is not), acid and alkali resistant suitable degree,import and export of the caliber size, whether the need for speed, lift (maximum statichead refers to the maximum height, no flow conditions of the pump pipe afterconnected vertical drawn so when the election of pump must choose a maximum head higher than his needs pump) and the size of the flow etc.. Other do notunderstand, please ask carefully before buying.
