VFO Series Industrial Dust Collector System

Model

VFO 3-12

VFO 3-24

VFO 3-36

VFO 3-48

VFO 3-60

VFO 3-72

Voltage (V/Hz)

380 / 50

Air flow (m³/h) /(CFM)

9000~15000 /
5300~8800

18000~30000 /
10600~17700

27000~45000 /
15900~26500

36000~60000 /
21200~35300

45000~75000 /
26500~44100

54000~90000 /
32000~53000

Power

Calculate the total pressure/static pressure according to the total resistance of the system, and then select the appropriate fan power

Filter area
(m²)/ ( sq.ft )

144 / 1550

288 / 3100

432 / 4650

576 / 6200

720 / 7750

864 / 9300

Filter efficiency

99%

Capacity of the dust container (L) / (gal)

100 / 26.4 (1pcs)

200 / 52.8 (2pcs)

300 / 79.2 (pcs)

400 / 105.6 (4pcs)

500 / 132 (5pcs)

600 / 158.4 (6pcs)

Noise dB (A)

82±2

83±2

85±2

85±2

88±2

90±2

Filter cleaning method

pulse jet cleaning+holder on dust collecting box

Dimension (Excluding the Blower)
[L*W*H] (mm) / (in)

1120*1910*3100 /
44.1*75.2*122.0

2240*1910*3640 /
88.2*75.2*143.3

3360*1910*3640 /
132.3*75.2*143.3

4480*1910*3640 /
176.4*75.2*143.3

5600*1910*3640 /
220.5*75.2*143.3

6720*1910*3640 /
264.6*75.2*143.3

Weight (kg) / (lb)

400 / 882

800 / 1764

1200 / 2646

1600 / 3528

2000 / 4410

2400 / 5290

※  The air flow and Negative pressure can be calculated according to the actual condition, and then choose the bigger or more suitable power machine.
