hydrauli rubber hose in competive price
CN ¥1.20

品牌：: GELEE

Model: SAE 100R1 AT

Origin: Made In China

Label: rubber hose , hydraulic hose , hydraulic rubber hos

Product name:Steel wire braided hydraulic hose: SAE 100R1 AT /DIN EN853 1SN

Instruction

Inner Tube: Oil resistant synthetic rubber.

Reinforcement: One high tensile steel wire braided (1W/B)

Cover: Abrasion and weather resistant synthetic rubber.

Temperature range: -40℃-＋100℃

Application: conveying petroleum-based hydraulic fluids, high pressure air and water,

The hose are available for hydraulic support, excavator,hydraulic equipment,air compressor,industrial machinery,machine tools, etc

I.D	Hose size		R .O.D	Hose O.D	Thickness of cover	MAX W.P		Min B.P	Min B.R	W.T	Length
Inch	Min mm	Max mm	mm	mm	mm	Mpa	psi	Mpa	mm	Kg/m	Meters
3/16”	4.6	5.4	9.0-10.0	12.5	0.8-1.5	25	3630	100	89	0.19	50/100
1/4”	6.2	7	10.6-11.6	14.1	0.8-1.5	22.5	3270	90	102	0.21	50/100
5/16”	7.7	8.5	12.1-13.3	15.7	0.8-1.5	21.5	3120	85	114	0.24	50/100
3/8”	9.3	10.1	14.5-15.7	18.1	0.8-1.5	18	2615	72	127	0.33	50/100
1/2”	12.3	13.5	17.5-19.1	21.4	0.8-1.5	16	2320	64	178	0.41	50/100
5/8”	15.5	16.7	20.6-22.2	24.5	0.8-1.5	13	1890	52	203	0.45	50/100
3/4”	18.6	19.8	24.6-26.2	28.5	0.8-1.5	10.5	1530	42	241	0.58	50/100
1”	25	26.4	32.5-34.1	36.6	0.8-1.5	8.8	1280	35	305	0.88	50
1-1/4”	31.4	33	39.3-41.7	44.8	1.0-2.0	6.3	920	25	419	1.23	20-40
1-1/2”	37.7	39.3	45.6-48.0	52.1	1.3-2.5	5	730	20	508	1.51	20-40
2”	50.4	52	58.7-61.7	65.5	1.3-2.5	4	580	16	635	1.97	20-40
