15000L fermentation tank/unitanks, jacketed beer fermenter

 FEATURES:

-Useful capacity: 15000 litres

-Insulation: polyurethane 100mm

-100% TIG welding with pure argon gas shield

-Cone bottom, 60-72 degree

-Cooling jackets on both cylinder and cone, SUS304, 1.5mm

-Interior Finish: Mirror polishing to 0.4~0.6μm without dead corner

-Dry hopping port on top

-Side mounted manway

-Carbonation stone (optional)

-Safety&vacuum valve on top

-Sample valve on side

-Test Pressure:0.3 Mpa,Working pressure 0.2Mpa.

-Rotating racking arm on cone with butterfly valve

-Discharge arm with butterflyvalve

-CIP arm with 360° coverage CIP spraying ball

-Thermowell with high accuracy temperaturesensor: PT100

Optional:

Capacity scope: 100L to 30000L per patch, can be customized

complete beer brewing system, include malt miller, brewhouse system, fermenting system, cooling system, CIP system, controlling system, filter system.

Beer bottling line: such as bottle filler, washer, capper, labeller.

Kegs washer and filler.
