2000L brewery equipment, fermentation tank

 MAIN CONFIGURATIONS:

 This brewhouse system includes 3 tanks(mash tun/lautering tun, brew kettle/whirlpool, hot liquor tank), please check the details in the following chart.

Optional:     1- mash/brew kettle, lauter tun/whirlpool, hot liquor tank

                     2- mash/brew kettle, lauter tun, whirlpool, hot liquor tank

                     3- mash tun, lauter tun, brew kettle/whirlpool, hot liquor tank

                     4- mash tun, lauter tun, brew kettle, whirlpool

This is the 2000L brewing system configuration for your reference.

Heating source: steam, electric or gas fired heating

Material: stainless steel 304/316

Warranty: 36 months for main tanks

Main features of brewhouse and fermentation:

Brewhouse system:

1) - Interior wall stainless steel 304, 3mm;

    - exterior wall stainless steel 304, 2mm

2) -Top manway with glass

     -Side manway, cone bottom 160 degree

3) - Insulation: polyurethane/rockwool 100mm;

     - with inside CIP washing ball

     - agitator

     - removable false bottom

    - sparging arm, sight glass

      -Tangential inlet for whirlpool

      -Thermowell for temperature sensor and thermometer....

Details:

Fermentation system:

1) - Interior wall stainless steel 304, 3mm;

      - exterior wall stainless steel 304, 2mm

 2) -Dome top, conical bottom,

     -Side mounted manway

3)  -Insulation: polyurethane 100mm

4)  -Glycol cooling jackets on both cylinder and cone

5)  - Inside 360 degree rotating CIP washing ball;

     - CIP arm

     - Pressure gauge

     - relief&vacuum valve on top

      -sample valve

     - rotating racking arm

     - thermometer

      -carbonation stone (optional)

     - dry hops port on top

 6)  -Testing pressure: 3 bar

      -working pressure: 1.5-2 bar

      -100% TIG welding with pure argon gas shield

      -Interior Finish:Mirror polishing to 0.4~0.6μm without dead corner

Reference:

1- For electrical elements part, we use SIEMENS, SCHNEIDER, DANFOSS, OMRON, ABB....etc. Also UL standard.

2. We have the capacity of 100L, 200L, 300L, 500L, 1000L, 2000L, 3000L, 5000L, 8000L, 10000L...( 1bbl, 2bbl, 5bbl, 10bbl....) per patch for your reference.

     It can be customized, such as the capacity, material, voltage, heating source, etc.

 3. The brewer can also brew draft beer, pale beer, brown beer, stout beer etc,

      to meet different taste of customers.

 OPTIONAL:

 Beer bottling line: bottle washing machine, filling machine, capping machine,

 pasteurization tank, labelling machine.

 Kegs washer and filler.

 Beer kegs(10L,20L,30L,50L...).

 Steam boiler.
