25W 30W Gimbal LED downlight

Description:

1. The directional fashionable integrated Gimbal LED downlight is specifically designed to achieve a pleasant and highlight image in commercial lighting.

2.The Kit includes a flicker-free driver and a die-casting aluminum integrated cooling radiator and solid mounting clips. The housing is finished with an internal reflector and tempered glass that provides glare free and uniform light distribution.

3.The housing is IP44 and completely closed so that insects can not penetrate.

4. With a lifespan of up to 50,000 hours this lumminaire is ideal for lighting systems in shops, museums, art galleries, exhibition halls, libraries, bakeries and many other commercial or private applications.

Features:​

CRI: 80+ ,90+(3000K/4000K/5000K)LED brand: Bridgelux, CREE, LuminusBeam angle: 15° / 24° / 38° / 60° are available Adjustable: Continuous 350° rotation and 90° pivot.Die-casting aluminum housingGood quality driver, flicker-free, PF>0.95   High luminous efficiency: 80-140lm/W @CRI80 (whole lamp)Wattage: 15W, 10W, 20W, 25W, 30W, 35W, 40W and 45WWarranty: 5 years.

Specification:

Model	LL-GDL160130-25W	LL-GDL160130-30W
Power（±10%）	25W	30W
Product Dimension	D160*H130
Cut out	D145mm
Input	AC200-240V / AC90-130V
Dimmable	DALI, TRIAC, O/1-10V, DMX, RF, ZigBee
Luminous Efficacy	80-140lm/W @CRI80 (whole lamp)
PF	>0.9
LED Type	Bridgelux
LED Q‘ty	COB
CCT(K)	2700K/3000K/4000K/5000K/6000K
CIR(Ra)	80, 90, 97
Beam angle	15° / 24° / 38° / 60°
Working Temperature	-20℃～45℃
Storage Temperature	-20℃～45℃
Adjustable	Adjustable
Housing color	White / Black
IP Grade	IP44
Body Materials	Aluminum Alloy
Certificate	CE, Rohs

Application:

Recessed lighting, shelf lighting, ceiling /wall coves, Cabinet and under counter lighting, office work station,Back lighting, step lighting light boxes, Merchandising, exhibition stands,and panels etc.
