COB round 12W trimless modular led downlight

Features:

Flexible design, one light module can work with different trim, you can change the trim and light module quickly without toolsCRI: 80+ ,90+(3000K/4000K/5000K)LED brand: Citizen, Bridgelux, CREE, LuminusDie-casting aluminum housingGood quality driver, flicker-free, PF>0.95   High luminous efficiency: 70-100lm/W @CRI80+Wattage: 5W, 8W, 10W, 12W, 15W, 20W and 25WThe downlight are flexible design, one light module can work with different trim, you can change the trim and light module quickly without toolsModular hotel LED downlight, the most important member of modular lighting,has come to markets. With modular lighting solution, it will be much flexible for your stock and projects.From now on, you can buy the whole lamps, you can buy trim, light module, driver separately and quick assemble or replace some accessories within 5 seconds, they will help you save 50% stock at least and meet clients’ various special requirements in shortest time.The light module can be single color, tunable white, DTW, with different light module can give different light output, different color, different CRI, different beam angle and lumen efficiency etc. With round and square shape, trim and trimless design, you can easily get different installation and lighting output, our patent design can give you very low UGR output,  It is also the best solution for after sales service, if you want to change which item, any one can do it quickly, no need electrician, can save a lot of time and money.



Specification:

Model	LL-DL7594-12W-3RT
Power（±10%）	12W
Product Dimension	D75XH94mm
Cut out	75-80mm
Input	AC200-240V / AC90-130V
Dimmable	DALI, TRIAC, O/1-10V, DMX, RF, ZigBee
Luminous Efficacy	70-100lm/W @CRI82 (whole lamp)
PF	>0.9
LED Type	Citizen, Cree, Bridgelux, luminus
LED Q‘ty	COB
CCT(K)	2700K/3000K/4000K/5000K/6000K
CIR(Ra)	80+,90+
Beam angle	15° / 24° / 36° / 60°
Working Temperature	-20℃～45℃
Storage Temperature	-20℃～45℃
Adjustable	Fixed and adjustable
Housing color	White
IP Grade	IP20
Body Materials	Aluminum Alloy + PC
Certificate	CE, Rohs

Application:

Recessed lighting, shelf lighting, ceiling /wall coves, Cabinet and under counter lighting, office work station,Back lighting, step lighting light boxes, Merchandising, exhibition stands,and panels etc.
