3.5 inch wireless touch screen video door phone intercom system

Specifications

1.3.5inch wireless video door phone
2. Touch screen
3. Time and date display
4. Photo-taking &storing
5. Build in battery

6.3.5inch wireless video door phone, video doorbell, intercom

Features

(1) 2.4GHz launch frequency, Approx 300meters barrier free remote control distance;

(2) With micro-processing technology, auto-remote control, excellent performance and high reliability;

(3) 3.5" TFT color display;

(4) 0.3Mega pixel camera;

(5) Clear night-viewing; 24hours monitoring, calling, speaking and unlocking remote controlling etc;

(6) One monitor for up to four cameras;

(7) Time shown on the indoor monitor;

(8) Rechargeable lithium battery through mini use charger;

(9) Monitor can take/ save/ view more than 100photos automatically;

(10) Build-in chord melodies;

Specifications

Working Distance: 100 - 300 feet
Video Compression: MJPEG
Audio Compression: ADPCM
Frequency: ISM 2,400 to 2,483 MHz
Transmission Power: 17dBm
Modulation: GFSK
Working Humidity: <85%

Outdoor Camera
Camera: 1/4 inch CMOS 300K pixels
Mini Illuminance: 0Lux (IR on)
Night Version: 6 IR LED lights, visible within 1 meters
Adapter Input: AC110~240V, 50/60Hz
Adapter Output: DC12V/1A
Power Consumption: Standby:0.12W; Working: 1.8W
Installation: Wall mounted
Size: 125*94*33mm
Material: ABS Plastic & Aluminum alloy

Indoor Monitor
Screen: 3.5 inch wide angle(65 deg) LCD screen
Resolution: 320*240 pixels
Image Record: Around 120 pieces color photos
Battery Bar Display: 5 grades
Signal Display: 6 grades
Power: By removable & rechargeable Lithium battery
Battery: 1350mAh; 3.7V
Power Consumption:
- Standby: 10mAh (0.04W)
- Working: 120mAh (0.45W)
- Max: 150mAh (0.56W)
Battery working time:
- Standby: 100 hours
- Continuous working: 8 hours
Charging time: 2-3hours (above 5 hours for the first time)
Adapter Input: AC110~240V, 50/60Hz
Adapter Output: DC5V/1A
Installation: Wall mounted/lift on desk/Portable
Material: ABS Plastic
Size: 140*85*21mm
Working Temperature: -25°C ~ 50°C

Package
1pcs * 2.4 GHz Wireless Transmitter with CMOS Camera Sensor
3pcs * 2.4 GHz Portable Wireless Receiver with 3.5 inch TFT/LCD Monitor
1pcs * AC Adapter
1pcs * Rechargeable Battery
1pcs * User Manual - English
