Metal housing waterproof standalone access control D008-C101

Features

 Low power consumption: less than 30mA standby current

 Luminous keyboard  for convenient use at night

 User capacity: support 2,000 users

Independent password: can use password which irrelevant with the card to open the door

User modification password: Users can revise the door password

Search speed: charge to open the door time less than 0.1 S.

Output short circuit protection: electric lock or alarm output circuit within 100 μS when shut down automatically output

Wiegand output: With Wiegand output interface，Wg26 card number

Usable keyboard delete card number:After card is lost, usable keyboard delete card， Thoroughly eliminate safety lapses

The demolition alarm:Illegal dismantling machine, built-in alarm sound buzzer

The bell button and interface: key and circuit segregation, external any the doorbell.



Technical parameters

Work Voltage：AC&DC9-28V

Static Current：≤30mA

Reading Range：3～8cm

Capacity: 2000 users

Ambient Temperature：-25℃～60℃

Ambient Humidity：10%～90%

Electricity lock output：≤3A

Alarm output：≤20A

Output short circuit protection time：≤100μS

Open time：0 ~ 99 seconds (adjustable)

Size：120 *80*25mm

Weight: 750g

Box Dimension: 19*13*6cm
