Bare Fiber Optical Splitter PLC SC LC FC ST SM MM

1×N bare PLC Splitter  Specification

Port

Configuration

Ch

1*2

1*4

1*8

1*16

1*32

1*64

Fiber Type

SMF-28e, G652, G655, G657 (or Customized)

Operating

Wavelength

nm

1260-1650

IL

Typical(dB)

≤3.9

≤7.2

≤10.3

≤13.6

≤16.9

≤20.2

UL

dB

≤0.5

≤0.6

≤0.8

≤1.0

≤1.3

≤1.8

PDL

dB

≤0.3

≤0.3

≤0.3

≤0.3

≤0.3

≤0.4

RL

dB

≥50

Directivity

dB

≥55

Operating

Temperature

℃

-40~+85

Storage

Temperature

℃

-40~+85

Steel Tube Size

mm

40*4*4

40*4*4

40*4*4

  50*7*4

50*7*4

60*12*4

2×N bare PLC Splitter Specification

Port

Configuration

Ch

2*2

2*4

2*8

2*16

2*32

2*64

Fiber Type

SMF-28e, G652, G655, G657 (or Customized)

Operating

Wavelength

nm

1260-1650

IL

Typical

(db)

≤4.0

≤7.6

≤10.8

≤14.1

≤17

≤20.5

UL

dB

≤1

≤1.4

≤1.5

≤2

≤2.5

≤2.5

PDL

dB

≤0.2

≤0.2

≤0.4

≤0.4

≤0.4

≤0.5

RL

dB

≥50

Directivity

dB

55

Operating

Temperature

℃

-40~+85

Storage Temperature

℃

-40~+85

Steel Tube Size

mm

60*7*4

60*7*4

60*7*4

60*7*4

80*20*6

/
