Dr. Schneider PC Overhead Ionized Air Blower

Line Voltage                 220VAC/ 50 Hz or 110VAC / 60Hz

Current Consumption          Max.1.25 Amp (fan high, light on)

                             Min.0.62 Amp (fan low, light off)

Air Volume Output            Fan speed Flow

Low 120 CFM

High 330 CFM

Air Flow Characteristics     40cm×120cm Area Coverage

Light Output                 1650 Lumens Total.

Replacement Lamp        13-15 Watt Energy Saving Fluorescent

Operating Temperature        32ºF(0℃)～122ºF(50℃)

Enclosure                     Aluminum

Finish                        Powder Coat

Size                         1100mm(L)×170mm(W)×125mm(H)

Optional Air Filter          30PPl Open Polyurethane Foam

Ion Balance(offset voltage)  0V+/-10V(It requires no calibration)

ION OUTPUT (DISCHARGE TIME):

1. Distance measured in mm, decay time measured in seconds.

2. Test data available using ME 268A charge plate analyzer.

3. Test figures are subject to the variation in the atmospheric

conditions.

4. Discharge times are in seconds from 1000 volts to 100 volts.
