Hirschmann GRS105/106 GRS105-6F8T16TSGGZ9HHSE2A swtich

Type GRS105-24TX/ GRS105-6F8T GRS105-16TX/ GRS105-6F8F GRS106-24TX/ GRS106-6F8T GRS106-16TX/ GRS106-6F8F describes the GREYHOUND 105/106 series, an industrial grade aggregation layer switch with network management, fanless design, 19 ˝ rack, up to 14 fiber ports, for a total of 30 ports. Port type and quantity 6 x 1/2.5GE SFP + 24x GE TX 6x 1/2.5GE SFP + 8x GE SFP + 16x GE TX 6x 1/2.5/10GE SFP + 8x 1/2.5GE TX + 16x GE TX 6x 1/2.5/10GE SFP + 8x 1/2.5GE SFP + 16x GE TX Interface USB-C 1 x USB-C (client), for local management use SD card slot 1x SD card slot, used to connect to automatic configuration adapter ACA31 Power Requirements Operating Voltage * Power Supply 1:24-48V DC, 110-250V DC or 110-240V AC Power supply 2: Not installed, 24-48 volts DC, 110-250 volts DC, or 110-240 volts AC Power consumption * The host comes with a maximum power supply of 35 watts Environmental conditions Operating temperature -10 ° C to+60 ° C Conformal coating optional Mechanical structure size (width x height x depth) 444 x 44 x 355mm Weight 5 kg Protection level IP20 software support HiOS software level 2 standard type (L2S), 2 advanced type (L2A) Certification basic standards CE, FCC, EN61131 Safety of industrial control equipment EN62368, cUL62368 Transportation EN50121-4 Accessories Order separately Network management Industrial grade HiVision, ACA31, SFP (+) transceivers
