Indoor Optic Cable Simplex Duplex Distribution Breakout GoodFtth_Telecommunication & Broadcasting_Electronics & Electricity_Products

Top Selling

品牌：: GoodFtth

Origin: Made In China

Label: simplex cable , duplex cable , multicore cable

Application:

Indoor distribution;

For patch cords and pigtails;

For communication equipment.

Feature:

Soft and flexible;

Excellent flame retardant performance;

Excellent tensile&crush strength;

Cable sheath options:PVC,LSZH,OFNP,etc.

Mechanical Characteristics:

Fiber Count	Cable Dimension (mm)	Cable Weight (kg/km)	Tensile Strength (N)		Crush Load (N/100mm)		Min.Bending Radius (mm)		Temperature Range (℃)
Fiber Count	Cable Dimension (mm)	Cable Weight (kg/km)	Long Term	Short Term	Long Term	Short Term	Dynamic	Static	-20~+60
1	1.6	2.2	40	80	100	500	50	30
1	1.8	3.0	40	80	100	500	50	30
1	2.0	3.6	60	100	100	500	50	30
1	2.4	5.0	60	100	100	500	50	30
1	2.8	6.5	80	150	100	500	60	30
1	3.0	7.4	80	150	100	500	60	30

Optical Characteristics:

		G652D	G657A1	G657A2	G.655	62.5/125	50/125
Attenuation (+20℃)	@850nm					≤3.0dB/km
	@1300nm					≤1.0dB/km
	@1310nm	≤0.36dB/km
	@1550nm	≤0.22dB/km			≤0.23dB/km
Bandwidth （Class A）	@850					≥500MHZ·km
Bandwidth （Class A）	@1300					≥600MHZ·km	≥1000MHZ·km
Numerical Aperture						0.275±0.015NA	0.200±0.015NA
Cut-off Wavelength		≤1260nm			≤1480nm
