LCF-23IRB RS232 Serial Camera(2M Pixel)

No.

Item

Description

1

Image sensor

CMOS

2

Pixels

2.0 mega pixels

3

Image Resolution

from 160X120 to 1600X1200

4

Image Compression

JPEG

5

Focal Length

3.6mm 6.0mm

6

Angle of View

90° 60°

7

Minimum lumen

1 Lux

8

Night Vision lumen

5 Lux

9

Night Vision Image

Black-White Image

10

Night Vision Distance

3-10M

11

Serial Interface

RS232 TTL RS485

13

Baud Rate

9600-115200bps ,128K,256K

14(1)

Connector

Customize for customer(any connector is available)

(2)

 PIN Description

PIN 1: DC 5V

PIN 2: TXD

PIN 3: RXD

PIN 4: GND

15

Length of Cable

Customize for customer(2m is default one)

16

White Balance

Automatic

17

Exposure

Automatic

18

Auto Gain Control

Automatic

19

Weight

0.4KG

20

Working Current

IR Off: 80-120mA

IR On: 250-320mA

21

Power Supply

5V

22

Working Temperature

-15°C~70°C

23

Datasheet/Protocol

LCF Protocol

24

PC Test Software

Support

25

Material of case

metal case

26

IP Rating

IP66
