LED emergency exit sign

LED Emergency Exit Sign Light

Name：Led Emergency Exit Sign Light
Model No.：YH-03S
Working Voltage：230V +/-10%
Frequency：50Hz
Viewing distance：25M(standard)/ 32M
IP Rating：IP40
Battery：4.8v NiCd
Materials：Aluminum housing + acrylic glass ledns Fittings included : Bracket



Easy to install--- four mounting ways
Screws fixed sign legends--- easy replacement, the legend panel is an optional part of the exit sign
Light source--- long life, ultra bright, energy saving, maintenance-free LED
Appealing, novel, high style design
High performance recharge and discharge protection system

Specification:

1,Option:Standard / self-test version
         Maintained, 3H / 1H duration
         Double side / single side
2,Materials :Aluminum housing + acrylic glass lens
3,Light source: 12 white LED (25M)
                15 white LED (32M)
4,Viewing distance: 25M (standard) / 32M
5,Available housing color: Aluminum (standard)
                           White / brass / chrome
6,Fittings included: Bracket
7,IP rating: IP 40
8,Supply voltage: 230v +/- 10%  50HZ
9,Battery: 4.8v NiCd
10,Dimensions: 25M   300mm* 218mm*54mm
               32M   360mm*248mm*54mm
11,Installation: Wall mounting, End mounting,
                 Ceiling mounting, Suspended mounting

Order code

Note: boxes 1 to 5 must be specified on all models with one single letter in each box.

1.     Versions

S --- Standard version   T --- Self-test version

2.     Emergency duration

T --- 3H duration   O --- 1H duration

3.     Double / single sided

D --- Double sided    S --- Single sided

4.     Housing color

A --- Aluminum  W --- White  B --- Brass finish  C --- Chrome finish

5.     Viewing distance

S --- 25M      L --- 32M

Example: YH-03S-STDAS

Present the YH-03S standard version, 3H duration, double sided, aluminum housing and 25M viewing distance Exit Sign

Pictogram / Legend

It fix on the arcylic board with screws, so it is very easy to change it according to your request.
