LILLIPUT 15.6inch UHD 12G-SDI,HDMI 2.0 broadcast production studio monitor

Short Description:

Lilliput Q15 is a professional production studio monitor, packed with features and facilities for the professional photographer, videographer, or cinematographer. Compatible with a multitude of inputs – and featuring the option of a 12G SDI and 12G-SFP Fiber Optic input connection for broadcast quality monitoring, It also features Audio Vectoring using a Lissajous graph shape allowing you to visualize the depth and balance of a stereo recording. You also can connect your computer to control the monitor via applications.



Brief Features:

15.6, UHD 3840*2160 ResolutionSupport standard 12G-SDI input interface (x2), 3G-SDI input interface (x2), and support Single-link, Dual-link and Quad-link signals.Support HDMI 2.0/1.4 inputs and loop outputs.Support SFP optical Connector input, optical module for optional.Loop output signals support up to 3840x2160 23.98/24/25/29.97/30/50/59.94/60p and 4096x2160 23.98/24/25/29.97/30/47.95/48/50/59.94/60p.Monitor control via LAN, GPI, RS422.Customized Menu Knob.Support customized various waveform mode: Waveform/Vector/Histogram/4 Bar Display/Audio Vector/Level Meter.HDR (High Dynamic Range) display supporting ST 2084 and Hybrid Log Gamma.Gamma selection: 1.8-2.8.Custom 3D LUT file load through USB.Wide color space supporting SMPTE-C, Rec709, EBU and Native.Color Space/ HDR/Gamma /Camera Log comparison with original (side by side).Color Temperature: 3200K/5500K/6500K/7500K/9300K/User.False Color: Default/Spectrum/ARRI/RED.Aspect Marker (16:9/1.85:1/2.35:1/4:3/2.0X/2.0X MAG/Grid/User).Aspect (Full/16:9/1.85:1/2.35:1/4:3/3:2/2.0X/2.0X MAG).Audio: supporting Audio Phase and Level Meter, HDMI supporting 8 channels, and SDI supporting 16 channels.TimeCode: LTC/VITC.UMD display:White/Red/Green/Blue/Yellow/Cyan/Magenta text color for optional.Color Bar Mode: Rec601/Rec709/BT2020.Check Field: Red/Green/Blue/Mono.Zoom at any position and at different scale.Peaking (Red/Green/Blue/White/Black).Tally (Red/Green/Yellow).



Specifications:



DISPLAY	Panel	15.6″
	Physical Resolution	3840*2160
	Aspect Ratio	16:9
	Brightness	330 cd/m²
	Contrast	1000：1
	Viewing Angle	176°/176°（H/V)
	HDR	ST2084 300/1000/10000/HLG
	Supported Log Formats	SLog2 / SLog3 / CLog / NLog / ArriLog / JLog or User…
	Look up Table(LUT)support	3D LUT (.cube format)
	Technology	Calibration to Rec.709 with optional calibration unit
VIDEO INPUT	SDI	2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad link)
	SFP	1×12G SFP+(Fiber module for optional)
	HDMI	1×HDMI 2.0
VIDEO LOOP OUTPUT	SDI	2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad link)
	HDMI	1×HDMI 2.0
SUPPORTED FORMATS	SDI	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…
	SFP	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…
	HDMI	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60…
AUDIO IN/OUT (48kHz PCM AUDIO)	SDI	16ch 48kHz 24-bit
	HDMI	8ch 24-bit
	Ear Jack	3.5mm
	Built-in Speakers	2
REMOTE CONTROL	RS422	In/out
	GPI	1
	LAN	1
POWER	Input Voltage	DC 12-24V
	Power Consumption	≤32.5W (15V)
	Compatible Batteries	V-Lock or Anton Bauer Mount
	Input Voltage(battery)	14.8V nominal
ENVIRONMENT	Operating Temperature	0℃~40℃
	Storage Temperature	-20℃~60℃
OTHER	Dimension(LWD)	393mm × 267mm × 51.4mm
	Weight	2.9kg
