Magnetic Lock 600lbs 280kg DW-280

Lock Size: 250Lx48.5Wx25H(mm)
Armature plate: 180Lx38Wx11H(mm)
Holding Force: 280kg(600Lbs)
Voltage: 12/24VDC+10%
Current Draw: 12V/500mA     24V/250mA
Suitable for: Wooden door , Glass door ,metal door , Fireproof door
Surface Temp: ≤+20℃
Operating Temp: 10～+55℃(14-131F)

Suitable Humidity:  0~90%(non-condensing)
Finishes for Shell: Anodized aluminum
Finishes for Magnetic: Zinc
Finishes for Armature: Zinc
Weight: 2kg
Standard Packing: 12pcs

Collinear Load Test 280kg,600pounds
Dual Voltage 12 or 24 VDC(optional)
The Standard Voltage is 12VDC when Finished
MOV Provides Reverse Current Protection
Anti-Residual Magnetism Designed
High Strength Material,Anodized Aluminum Housing
Design without Mechanical Failure

Increase the holding Force,Dual Insulative Housing
